4. Connect the coaxial cable of the antenna to the "ANTENNA" socket of
tuner.
5. Grounding the tuner will enhance its performance and safety. We
recommended that you connect tuner to a suitable ground; a common
ground rod connected to buried radials is preferred, but a single ground rod,
a cold water pipe, or the screw that holds the cover on an AC outlet can
provide a serviceable ground. We strongly recommended the use of a
properly installed, high quality lightning arrestor on all antenna cables.
TRANSCEIVERS SETTING
Some transmitters can operate the external tuner normally without the need
for menu settings, while others must have the necessary menus set before
operating the external tuner. Please carefully read the transmitter's operating
manual on how to set up the external tuner menu for the transmitter. Different
transmitters require different menu settings.

OPERATION

If you are not satisfied with your current SWR, you can start a new tuning cycle.
Read your transmitter's operating manual to learn how to initiate a tuning
cycle. Usually you only need to hold down the [TUNE] or [AT] button on the
front panel for more than 1 second to start a new tuning cycle. Some
transmitters can switch the tuner's "ONLINE/BYPASS" status and activate or
deactivate the tuner by quickly pressing and releasing the [TUNE] button.
Other transmitters do not have this switching function, and you have to keep
the tuner online all the time.
We will occasionally update tuner operation videos on our YouTube channel to
help users understand how to operate our tuners. Our channel is "MAT-TUNER
TUNER". You can subscribe to our channel to learn more operational
information.

SUPPLIED ACCESSORIES

mAT-CI Control cable
mAT-M200 instruction1pc

TECHNICAL SUPPORT

● Frequency range: 1.8 ~ 54 MHz
● Maximum input power: 200W(SSB)，100W(DATA mode)
● Tuning time: Maximum 5 seconds (Full tuning)
1pc
0.1 seconds (Memory tuning)
