- Page 1 SCF-200/SCF-210P/SCF-220D CONFERENCE SYSTEM N Instruction manual SCF-220D SCF-210P Delegate microphone President microphone SCF-200 Control unit...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions
13.- TEL: connection to the telephone line with an RJ-11 connector. 14.- PHONE: telephone connection with an RJ-11 connector. This connection allows a teleconference. 15.- 220 V AC, 50 Hz mains connection. PRESIDENT MICROPHONE AND DELEGATE MICROPHONE SCF-220D Delegate Microphone SCF-210P President Microphone... -
Page 5: Installation And Connection
1.- Prepare the control unit model SCF-200, the president microphone model SCF-210P and the delegate microphones model SCF-220D for connection. The control unit model SCF-200 is supplied with a 5 m extension lead with male DIN-8 to female DIN-8 connectors to interconnect equipment, a 6.3 mm jack to 6.3 mm jack cable for audio output and the power supply cable. - Page 6 3.- Connect the DIN-8 connector from one of the ends of the extension lead to one of the two GROUP sockets (GROUP I or GROUP II) on the control unit. Connect the DIN-8 connector from the other end of the extension lead to the input on the extension lead with adapter. 4.- Connect a microphone to one of the other inputs of the extension lead with adapter.
-
Page 7: Specifications
1 x 5m extension cable to interconnect male DIN 8 and female DIN 8 microphones (Please enquire for other lengths) 1 x 1m audio cable, 6.3 mm mono jack to 6.3 mm mono jack SCF-210P SCF-220D CHARACTERISTICS President microphone with Delegate microphone. -
Page 8: Declaration Of Conformity
This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los...
