- Page 1 SCI-700, SCI-705R, SCI-710P and SCI-720D WIRELESS UHF CONFERENCE SYSTEM N Instruction manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
(mobility and easy installation). The control unit SCI-700 has a capacity for 6 SCI-705R receiver modules. The conference system can be increased with another control unit taking the capacity of the system up to a total of 12 microphones. Just one SCI-710P president microphone can be used with up to 11 SCI-720D delegate microphones. -
Page 4: Controls And Functions
- Switch activated microphones. - Can be increased with another additional secondary control unit (12 receiver modules in total). SCI-705R Receiver Module - UHF 863-865 MHz receiver module. - Information display with (RF) radio frequency signal, (AF) audio frequency signal and frequency reception indicators. -
Page 5: Back Panel
LED indicator showing the active microphones at that moment. Receiver aerials for the microphone signal. 10. Blank panels for uninstalled receiver module holes or SCI-705R receiver modules. BACK PANEL 1, 7. AERIAL A, AERIAL B: aerial connectors, supplying a +8 V DC voltage, 150 mA phantom for the power supply of an aerial amplifier. - Page 6 SCI-705R RECEIVER MODULE 1.- RF: RF radio frequency signal level indicator. 2.- AF: AF audio signal level indicator. 3.- Module operating frequency indicator. 4.- UP, DOWN: module operating frequency, channel, squelch level (SQ) selection buttons and button block. See INSTRUCTIONS FOR USE section for more information.
- Page 7 9.- Battery holder compartment for 2 x 1.5 V LR6-AA batteries. CONNECTION Connection between SCI-700 units Place the systems where you want them to be installed. Before switching them on, make the connections as shown in the following example. Example of the installation of 2 SCI-700 control units Firstly, connect all the SCI-700 unit aerials.
-
Page 8: Setting The Main Unit
INSTRUCTIONS FOR USE INSTALLATION OF RECEIVER MODULES SCI-705R The conference system lets you use up to 12 wireless microphones which have to be accompanied by their respective receiver modules. To extract or insert receiver modules, you must remove the lid from the control unit. -
Page 9: Squelch Adjustment
The operating frequency for the receiver module can be chosen manually. To do this, press down the IR/SET button for a few seconds. With the UP/DOWN keys select the TURN option and press the IR/SET button again. Afterwards, with the UP/DOWN keys choose the desired operating frequency for that module. After changing the transmission frequency, the new transmission channel must be sent to the microphone using The operating frequency for the receiver module can be chosen from the three pre-tuned channels in each receiver. -
Page 10: Specifications
1.2m audio cable, 6.3 mm mono jack to 6.3 mm mono jack 1 m interconnection cable, CAT-5 Blank panels for empty receiver holes (in this case) SCI-705R:UHF wireless conference system receiver module OPTIONAL SCI-710P: Wireless desktop president microphone SCI-720D: Wireless desktop delegate microphone AMP-800S: Aerial amplifier... - Page 11 SCI-705R UHF receiver module. CHARACTERISTICS For UHF wireless conference system control unit. PLL tuner. IR transmission of the channel to the microphone. CONTROLS Channel selection and blocking Squelch adjustment RESPONSE 50-18 000 Hz INDICATORS LCD screen, channel visualization, RF signal level and AF level ALIMENTACIÓN...
-
Page 12: Declaration Of Conformity
This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los...
