- Page 1 SCF-500 CONFERENCE SYSTEM EN Instruction manual SCF-520D SCF-510P Delegate Microphone President Microphone SCF-500 Control unit/Amplifier...
-
Page 2: Security And The Environment
We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine. -
Page 3: Table Of Contents
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Description
DESCRIPTION This FONESTAR Conference system model SCF-500 is suitable for P.A. and communication in congresses, parliaments, Town Halls, Courts, board of directors, seminars, round tables, debates and in general wherever P.A. and communication is needed among different people. The system offers very clear audio with a very low noise level. - Page 5 BACK PANEL 1- LINK 1 - 3: socket for interconnecting microphones. Control and audio signal for the conference system microphones. Each “LINK” socket can take up to 25 microphones. 2- L.SPEAKER: volume control for the microphone monitor speakers. 3- STAND BY: future upgrades. 4- SPEED DOME: future upgrades.
-
Page 6: Installation And Connection
1.- Prepare the control unit model SCF-500, the president microphones model. SCF-510P and the delegate microphones model SCF-520D. The control unit model SCF-500 is supplied with a 12 m interconnection cable with a male sub “D” 9 connector for connecting it to the control unit and a male DIN-8 connector for connecting microphones. - Page 7 INSTALLATION EXAMPLE UP TO 10 PRESIDENT MICROPHONES UP TO 75 MICROPHONES IN TOTAL 4- Use low Z (8 Ω) speakers to be connected to the amplifier output and reproduce the conference audio. 5- To connect an audio splitter use the “AUX OUT” output. 6- With all the controls at their minimum, connect the control unit to the electrical power and switch the system on.
- Page 8 MIC CONTROL This control lets you select the maximum number of delegate microphones active at the same time. Using the selector you can switch between the number of delegate microphones that can be active. If you do not select a quantity, you will only be able to activate the president microphone and the delegate microphones cannot be used.
- Page 9 INTERCONNECTION CABLE Male SUB D-9 (pin view) Male DIN D-8 (pin view) Male DIN-8 Male SUB D-9 pins pins Signal +18 V +18 V MIC R MIC L Mesh Mesh Female DIN-8 Female DIN-8 “Y” INTERCONNECTION CABLE pins pins Signal R x D Male DIN-8 Female DIN-8...
-
Page 10: Specifications
SPECIFICATIONS SCF-500 Control Unit Control unit for system power supply. CHARACTERISTICS Integrated amplifier. System test. Control of number of microphones in use. Disconnects unused microphones. Distribution or recording output. Allows the connection of up to 75 microphones. POWER 2 x 40 W RMS at 8 Ω... - Page 11 SCF-510P SCF-520D President microphone with speech CHARACTERISTICS Delegate microphone. priority and possibility of cancelling Monitor speaker incorporated. delegate microphones. Metal microphone base. Monitor speaker incorporated. Metal microphone base. MICROPHONE Unidirectional electret condenser RESPONSE 120-16 000 Hz CONTROLS Priority and on/off on/off INDICATORS LED ring and buttons with backlight...
-
Page 12: Declaration Of Conformity
This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los...
