KÜBLER SPORT D5128 Assembly Instruction

Small training goal, profi completely welded 1.80 x 1.20 m

Download this manual

Assembly instruction

Small training goal;

Completely welded

1.80 x 1.20 m

Cat.-No.: 2471626, 2471639

D5128

Thanks for choosing Sport-Thieme equipment. In order to enjoy this product please note the

following instructions for safety, use and maintenance before assembly.

As this goal is completely welded only the net needs to be mounted at the goal (see point 2).

1. Scope of delivery:

Please check the following content before assembly.

Piece

2. Assembly of the net:

Make sure that the groove of the goal is clean and all packing material or other

material is removed so that the assembly is possible without any problems.

Now fix and adjust the net rope in the groove. Then stick net holders with its clips into

the groove and fix them with a 90° rotation. Fixing is either possible manually, with

the key for hexagon socket screws or with a pliers (see bottom pictures). Distribute

net holders equally (same distances).

PROFI

Kübler Sport

Description

Completely welded goal

Net with fixing cord

Accessories:

45 x net holder

2 x plastic stopper Ø 28mm

1 x hexagon screwdriver SW5

1 x assembly instruction

Accessories:

Need help?

Do you have a question about the D5128 and is the answer not in the manual?

Page 1 Small training goal; Completely welded 1.80 x 1.20 m Cat.-No.: 2471626, 2471639 D5128 Thanks for choosing Sport-Thieme equipment. In order to enjoy this product please note the Kübler Sport following instructions for safety, use and maintenance before assembly. As this goal is completely welded only the net needs to be mounted at the goal (see point 2).
Page 2 We recommend the following distribution of net holders: crossbar : 10 pieces upright : 7 pieces each ground bar : 5 pieces each ground tube : 10 pieces Use all the other included net holders for corners and other connections. Pull the cord through each net meshes and fix it on both net hoops, if necessary lead it through the bore in the net hoop.
Page 3 5. Inspection and maintenance: a) Visual inspections should routinely be realized before each use. b) Functional inspections should take place at least every six months or according to manufacturer’s instructions/national regulations/standard specifications. c) A general inspection should be realized at least once a year or according to manufacturer’s instructions/national regulations/standard specifications.
