KÜBLER SPORT D5127 Assembly Instruction

Assembly instruction
Small training goal;
Completely welded
1.20 x 0.80m
Cat. -no.: 2471600, 2471613,
D5127
2618702, 2618715
Thanks for choosing Sport-Thieme equipment. In order to enjoy this product please note
the following instructions for safety, use and maintenance before assembly.
As this goal is completely welded only the net needs to be mounted at the goal (see point 2).
1. Scope of delivery:
Please check the following content before assembly.
Piece Description
1 Completely welded goal
1 Net
1 Accessories:
2. Assembly of the net:
Make sure that the groove of the goal is clean and all packing material or other material
is removed so that the assembly is possible without any problems.
Now fix and adjust the net rope in the groove. Then stick net holders with its clips into
the groove and fix them with a 90° rotation. Fixing is either possible manually, with the
key for hexagon socket screws or with a pliers (see bottom pictures). Distribute net
holders equally (same distances).
PROFI
Kübler Sport
- 35 x safety system net holder
- 2 x plastic stopper Ø 28mm
- 1 x hexagon screwdriver SW5
- 1 x assembly instruction
Accessories:
4
