ST-WIFI-G2 User Manual V1.2
ST-WIFI-G2 User Manual - V1.2
RENAC Power Technology Co., LTD.
Electrical connection
□
1
Plug the ST-WIFI-G2 module into the COM port of the inverter.
The inverter models shown are for illustrative purposes only and
are not exclusive to this model.
Turn on inverter and check ST-WIFI-G2 state
□
2
After installing the ST-WIFI-G2 module, turn on the inverter, below
is the LED state of the module.
LED State Indication
LED off The module has no power supply and is
not working correctly.
LED green and blinking The module is searching network
and under WIFI configuration.
LED stay on green The WIFI configuration is successful.
LED stay on red 1. The module powers up normally;
2. The module enters AP mode.
Registration and adding device
□
3
1. Download & Install Mobile APP
1.1 Download APP.
Scan the QR code below to download Renac SEC; Android users can
install the APP by downloading the APK file. Also, you can search
for Renac SEC in iOS or Google Play Store, download it, and install
it.
NOTE
1.2 Install <Renac SEC> & Enable Permissions.
After installed APP on mobile phone, please set all the permissions
of the APP to be enabled in the ''Settings''-''Apps''-''Permissions''.
2. Registration
2.1 Make sure your phone's location permissions and Bluetooth
permissions are turned on.
2.2 Register an account.
Open the APP, fill out requirement information to create a new
account, then click "Submit".
2.3 Add a new station.
Add the power station page, fill in the corresponding information,
and click "Submit" at the bottom to add a new power station (if you
do not need to associate the installer account, you can ignore the
"installer" item. Items marked with * are required.)
After adding a new station, back to the home page, and the newly
added power station will be shown in the station list.
When creating a new station, you must ensure that the station type
matches the current device type. Otherwise, an error will be
reported on the APP interface.
2.4 Add a device.
Click on the newly added power station, and click "+" and scan the
QR code (charger serial number) on the device label to add a
device.
NOTE
1
