Renac ST-WIFI-G2 User Manual

ST-WIFI-G2 User Manual V1.1
RENAC Power Technology Co., LTD.,
Electrical connection
Plug the ST-WIFI-G2 module into the COM port of the inverter.
Turn on inverter and check ST-WIFI-G2 state
After installing the ST-WIFI-G2 module, turn on the inverter, below is the
LED state of the module.
LED State
The LED default is off before pressing
LED off
LED green and blinking
LED stay on green
Registration and adding device
1. Download & Install Mobile APP
1.1 Scan the QR code below to download Renac SEC, also you can search
Renac SEC in iOS or Google Play Store, download and install it.
Android & iOS
1.2 Install <Renac SEC> & Enable Permissions
After installed APP on mobile phone, please set all the permissions of the
APP to be enabled in the ''Settings''-''Apps''-''Permissions''.
2. Registration
then click "Submit".
Indication
The module is searching network
2.2 After entering the newly created account, the system will automatically
enter into the "Add station" page.
Remark:
If you want to add more stations to an existing account, after entering into the account,
click " " on the home interface to enter to the station list, and click "+" to add a station.
2.3 If the pop-up message is as shown below,please turn on mobile phone's
GPS and click "OK". Thus the system will automatically locate the longitude
and latitude of the power station.
Capability Size(kW)
RENAC SEC
Please turn on GPS,and we can get the
location of the station by GPS
Proflt ratio
to add a new power station.
Note:
For 'Installer' option, enter the installer account' name will add this power station to this
installer account.Keep it empty if it is not sure. The station type must be chosen correctly.
2.5 After adding the power station, back to home page, and the newly added power
2.7 Click "+" and scan the QR code (inverter serial number) on the device label to
add a device.
Inverter serial number
OK
