  • Page 3: Table Of Contents

    Turbo H1 Series User Manual Content 1. About this manual ................................4 1.1 Applicability ................................4 1.2 Target group ................................4 1.3 Symbols used ................................4 1.4 Designation in the document ............................. 4 2. Safety ....................................5 2.1 General safety ................................5 2.2 Important safety instructions .............................
  • Page 4 Turbo H1 Series User Manual 8. Decommissioning ................................24 8.1 Dismantling the battery ............................24 8.2 Packaging .................................. 24 8.3 Storage..................................24 8.4 Disposal ..................................24...
  • Page 5 Copyright Declaration All rights to the content of this manual are owned by RENAC Power Technology Co., Ltd. (hereinafter called as RENAC Power). Any corporation or individual should not plagiarize, partially copy or fully copy it, and no reproduction or distribution of it in any form or by any means without prior written permission from RENAC Power.

  • Page 6: About This Manual

    Turbo H1 Series User Manual 1. About this manual 1.1 Applicability Please read the product manual carefully before installation, operation or maintenance. This manual contains important safety instructions and installation instructions that must be followed during installation and maintenance of the equipment.

  • Page 7: Safety

    2.1 General safety The Turbo H1 Series battery is for residential and works with a photovoltaic system. It is a high voltage Li-ion battery storage system, with the control module on itself. It could be operated in on-grid, off-grid and backup modes with compatible inverters.

  • Page 8: Explanation Of Symbols

    Full protective clothing and self-contained breathing apparatus are for the firefighters to extinguish the fire. Damage to the battery system due to under voltages If the battery system doesn't start at all, please contact Renac after-sales service within 48 hours. Otherwise, the battery could be permanently damaged. NOTE! Electrical installation and maintenance must be carried out by competent electricians according to local regulations.

  • Page 9: Introduction

    Threaded Leveling Legs Figure 3-1 PV Energy Storage System (TB-H1-14.97 is used as example) Note: The Turbo H1 series battery consists of a battery master controller and rechargeable battery stacks. BMC model name is BMC600.RBS model name is B9639-S. Battery Capacity Description...

  • Page 10: Terminal

    Turbo H1 Series User Manual Figure 3-2 Battery Capacity Description 3.2 Terminal BMC view: Figure 3-3 Terminals of BMC600 Object Description Alarm LED Running LED Start button DC isolator Communication port Battery terminals connect with B9639-S (BAT+/BAT-) Battery terminals connect with hybrid inverter (BAT+/BAT-)

  • Page 11: Technical Data

    Turbo H1 Series User Manual RBS view: Figure 3-4 Object Description BAT- connector COM 1 COM 2 BAT+ connector 4. Technical data Model TB-H1-3.74 TB-H1-7.48 TB-H1-11.23 TB-H1-14.97 TB-H1-18.7 Electrical Parameters Nominal 3.74 7.48 11.23 14.97 18.7 Energy[1](kWh) Usable Energy 3.36 6.73...

  • Page 12: Installation

    [1] Nominal Energy: Test conditions: 100% DOD, 0.2C charge & discharge at + 25C. [2] The recommended charging and discharging current is 20/20A. [3] Ambient temperature : Charging (0 ~ +40℃), Discharging (-10 ~ +50℃). [4] Conditions apply. Refer to Renac Power Battery Warranty Policy! 5. Installation 5.1 Unpacking Check the delivery for completeness.
  • Page 13 Turbo H1 Series User Manual Object Quantity Description Battery Master Controller (BMC600) with floor-mounted base BMC protective cover Bracket Battery Connectors(1* positive,3*negative) DC input power cable(inverter to battery, 1.5m, B- to B-，2m) DC input power cable (B+ to B+) Signal cable(BMC to RBS) Signal cable(1.5m)

  • Page 14: Check For Transport Damage

    5.2 Check for transport damage Check if the Turbo H1 series battery has some visible external damage, such as cracks in the housing or display please contact with your dealer if you find any damage.

  • Page 15: Available Space

    Turbo H1 Series User Manual The altitude of the installation location should be less than 2000m. The ambient temperature should be between -10℃and +55℃. The ambient humidity should be between 5-95%. Figure 5-4 5.4 Available space Figure 5-5 Battery space size 5.5 Preparation...

  • Page 16: Installation Steps

    Turbo H1 Series User Manual Hammer Hanging the bracket KIMO 20V 1/2 Cordless Brushless Impact Hanging the bracket Wrench Set Screwdriver Wiring RJ45 Crimping Tool Crimping plier for PV cable Crimping Tool For Insulated Crimping plier Electrical Connectors 5.6 Installation steps Take the BMC and base out of the package.
  • Page 17 Turbo H1 Series User Manual Right Left Bottom Battery Base Figure 5-8 Drill holes with Φ10 driller carefully, make sure the holes are deep enough(at least 45mm)for installation, and tighten the expansion tubes. Install the expansion tubes in the holes, and tight them. Install the wall bracket using the expansion screws in the screw package.

  • Page 18: Electrical Wiring Connection

    Turbo H1 Series User Manual Figure 5-9 Secure the RBSs each other and BMC with RBS using M5 screws. NOTE! The number of RBS is determined by the customer's actual usage. The installation illustration is based on five battery clusters as an example. The RBS bracket can be dispensed with.

  • Page 19: External Electrical Connection Of The Battery

    Turbo H1 Series User Manual DC input power cable (B+ to B+) Signal cable (BMC to RBS) Ground cable DC input power cable (B+ to B+) Signal cable (RBS to RBS) CAN communication terminator resistor DC input power cable (B- to B-)
  • Page 20 Turbo H1 Series User Manual Figure 5-12 Push the insert into the sleeve (Figure 5-13, C). Tighten the cable gland to 2 Nm (Figure 5-13, D) Use a suitable and calibrated torque wrench, size 15. Use an open-jaw wrench, size 16 to hold the connector in place.

  • Page 21: Earth Connection

    Turbo H1 Series User Manual Figure 5-15 Function CANH CANL Overview for all battery connections Figure 5-16 5.7.3 Earth connection The BMC and RBSs must be connected to a protective conductor. For this purpose, a line from the potential equalization rail to the floor mounted base must be installed expertly.
  • Page 22 Turbo H1 Series User Manual Suit the ring terminal on the earthling connector.  Suit the gasket on the earthling connector.  Screw the screw of the earthling connector.  Figure 5-17 Mark the product type on the following label...

  • Page 23: External Protective Cover Installation

    Turbo H1 Series User Manual 5.8 External protective cover installation After electrical connections are complete, check all the wiring is correctly and securely connected, install the external protective cover, and secure it using M4 screws. Figure 5-19 5.9 Overview for all battery clusters connectionist 5.9.1 Cobles connection...

  • Page 24: Dip Switch Description

    Turbo H1 Series User Manual Note: For the parallel connection of 2 battery clusters and 3 battery clusters, please use the power cable in an accessory bag of  the battery package to make the connection. For the parallel connection of 4 battery clusters and 5 battery clusters, please use the power cable in an accessory bag of ...

  • Page 25: Switch On The System For Multiple Battery Clusters

    Green Battery system workable Battery system faults or warning If faults, warning or events of the battery occur, these are reported on the display of the inverter or can be called up via the Renac SEC. 7. Troubleshooting LED state...
  • Page 26 Do not dispose of the battery system with your household waste.  Avoid exposing the batteries to high temperatures or direct sunlight.  Avoid exposing the batteries to high humidity or corrosive atmospheres.  For more information, please contact Renac.  User Manual Download URL www.renacpower.com 422-00010-01...
