ENGLISH

1. PARTS AND COMPONENTS

Fig. 1
1. Filling opening
2. Water inlet cover
3. Water tank
4. Unit base
5. Cord slot
6. Temperature knob
7. Soleplate
8. Handle
9. Steam trigger
10. Lock button
11. Iron
12. Heatproof stand
13. Control panel
Temperature knob
Fig. 2.
1. 170 ºC-225 ºC (Maximum)
2. 140 ºC-210 ºC
3. 100 ºC-160 ºC
4. 70 ºC-120 ºC (Minimum)
Buttons and light indicators
Fig. 3
1. Power indicator
2. Descaling indicator
3. Refill indicator
4. Power switch
5. Low-steam rate indicator
6. Medium-steam rate indicator
7. High-steam rate indicator
8. Steam-power level button

2. BEFORE USE

Take the product out of the box.
Remove any packaging materials, stickers or protective foil from the soleplate.
Clean the soleplate with a soft cloth.
