Cylindrical photoelectric sensor in M18 stainless steel housing
E3F2-SUS
The stainless steel housing provides enhanced
detergent resistance and longer lifetime in demanding
environments.
• Complete sensor portfolio in robust stainless steel
housing
• IP67, IP69K for highest water resistance
• Enhanced detergent resistance (ECOLAB certified)
• High power LED to compensate for dirt and misalign-
ment
Selection Guide
Sensing method
Through-beam
Retro-reflective with M.S.R.
Diffuse-reflective
Diffuse-reflective
(background suppression)
*1.
Pre-wired connectors are available on request. Contact your OMRON representative.
*2.
Order reflector separately
*3.
Measured with E39-R1S
Note: Standard cable length is 2 m. Models provided with a 5 m long cable are available. When ordering, specify the cable length by adapting the length of the cable
(e.g. E3F2-R4B4-S-E 5M). For other cable length please contact your OMRON sales representative.
E3F2-SUS
Sensing
Connection method
distance
7 m
–
–
*2
0.1 to 4 m
–
*3
(adjustable)
–
0.1 m (fixed,
–
wide beam)
–
0.3 m
–
(adjustable)
–
0.1 m (fixed)
–
–
Order code
PNP output
*1
E3F2-7B4-S 2M
–
2 m
–
*1
E3F2-7B4-M1-S
–
–
*1
E3F2-R4B4-S-E 2M
–
2 m
–
*1
E3F2-R4B4-M1-S-E
–
–
*1
E3F2-DS10B4-S 2M
–
2 m
–
*1
E3F2-DS10B4-M1-S
–
–
*1
E3F2-DS30B4-S 2M
–
2 m
–
*1
E3F2-DS30B4-M1-S
–
–
E3F2-LS10B4-S 2M
*1
–
2 m
–
E3F2-LS10B4-M1-S
*1
–
–
NPN output
E3F2-7C4-S 2M
E3F2-7C4-M1-S
E3F2-R4C4-S-E 2M
E3F2-R4C4-M1-S-E
E3F2-DS10C4-S 2M
E3F2-DS10C4-M1-S
E3F2-DS30C4-S 2M
E3F2-DS30C4-M1-S
E3F2-LS10C4-S 2M
E3F2-LS10C4-M1-S
1
Advertisement
Table of Contents
Related Manuals for Omron E3F2-SUS
Summary of Contents for Omron E3F2-SUS
- Page 1 Measured with E39-R1S Note: Standard cable length is 2 m. Models provided with a 5 m long cable are available. When ordering, specify the cable length by adapting the length of the cable (e.g. E3F2-R4B4-S-E 5M). For other cable length please contact your OMRON sales representative.
- Page 2 Mounting Bracket Y92E-B18 screw mount Values in parentheses indicate the minimum required distance between the sensor and reflector. Note: For detailed information about Accessories, refer to the main chapter “Accessories” at the end of the document. Sensor I/O Connectors Cord Shape...
-
Page 3: Specifications
Stainless steel The IP69k test according to DIN 40 050 part 9 is intended to simulate high pressure/steam cleaning. During the test 14-16l/min water at 80°C is sprayed onto the sensor from different angles with 8000-10000kPa. The sensor may not suffer any damaging effects from high pressure water in appearance and functionality. -
Page 4: Engineering Data (Typical)
(100 x 100 mm) –10 –20 Sensing distance adjustable between 0 and 550 mm Object –30 –40 Distance X (mm) Excess Gain Ratio vs. Distance (typical) Through-beam Models Retro-reflective Models Diffuse-reflective Models E3F2-7#4-# E3F2-R4#4#-# E3F2-DS10#4-# (wide beam type) Reflectors: Sensing object:... - Page 5 100 x 100 mm White paper (90% reflectivity) Grey paper (18% reflectivity) 1000 Distance X (mm) Light spot vs sensing distance Incline (left and right) Incline (up and down) Background suppression Models Background suppression Models Background suppression Models E3F2-LS# E3F2-LS#...
-
Page 6: Operation
Operation Output Circuits Structure of Sensor I/O Connector Connector Classification Wire color pin No. Brown Power supply ➀ Brown White (+V) Blue Mode selec- ➁ Black White tion Lon/Don Power supply ➂ Blue (0 V) Output XS2F-D42#-D80-# ➃ Black XS2F-G42#-G80-#... - Page 7 ON when light 100 mA indicator pink (Pin ➁) Load circuit max. Blue is interrupted. (orange) and blue Output (Dark-ON) (Pin ➂) cords. Pink transistor Mode selection Load Operate Connector Pin Arrangement (relay) Release Note: Terminal numbers for connector type. E3F2-SUS...
- Page 8 ON when light is Blue indicator pink (Pin ➁) (orange) interrupted. (Dark- = 36 V and blue Output Pink (Pin ➂) cords. Mode selection transistor Connector Pin Arrangement Load Operate (relay) Release Note: Terminal numbers for connector type. Standard Photoelectric Sensors...
- Page 9 Dimensions Note: All units are in millimeters unless otherwise indicated Cable type Connector type Without potentiometer E3F2-7#-S E3F2-7#-M1-S E3F2-DS10#4-S E3F2-DS10#4-M1-S E3F2-LS10#4-S E3F2-LS10#4-M1-S 4.8 dia 4.8 dia 64.9 65.5 42.3 42.3 optical optical area area Light indicator Light indicator M18x1 6g...
- Page 10 E39-RS2 Adhesive tape side 4-R1 Adhesive Reflecting tape surface 4 x R1 Installation Mounting Bracket Y92E-B18 Lens Cap E39-F31 Glass plate E3F2 Metal rim Gasket 4 max. 20 dia. Note: Hexagon bolt: M5 x 32 Material: plastic Standard Photoelectric Sensors...
-
Page 11: Safety Precautions
This Sensor is equipped with load short-circuit protection, but be Do not attempt to disassemble, repair, or modify the Sensor. sure to not short circuit the load. Be sure to not use an output cur- Outdoor Use rent flow that exceeds the rated current. If a load short circuit oc- Do not use the Sensor in locations subject to direct sunlight. - Page 12 This is not intended to be an exhaustive list OMRON shall not be responsible for the user’s programming of a pro- of all possible uses of the products, nor is it intended to imply that the grammable product, or any consequence thereof.
