Installation Guide
MHM-97923-PBF, Rev 2.10
March 2024
AMS Asset Monitor
Online Prediction, Protection, and Process Monitor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMS and is the answer not in the manual?

Questions and answers

Related Manuals for Emerson AMS

Summary of Contents for Emerson AMS

  • Page 1 Installation Guide MHM-97923-PBF, Rev 2.10 March 2024 AMS Asset Monitor Online Prediction, Protection, and Process Monitor...
  • Page 2 Information in this document is subject to change without notice and does not represent a commitment on the part of Emerson. The information in this manual is not all-inclusive and cannot cover all unique situations.
  • Page 3 Opmerking m.b.t. installatie van elektrische meet circuits in explosiegevaarlijke omgeving Dient de installatie van elektrische meet circuits in een explosiegevaarlijke omgeving te geschieden, moet men toezien dat de in de gebruikshandleiding opgenomen installatieinstructies worden nageleefd. Bij taalkundige problemen gelieve contact op te nemen met de fabrikant, deze zal u vervolgens een vertaling in de taal van het gebruiksland doen toekomen.
  • Page 4 Piezīme par mērīšanas ķēžu instalēšanu sprādziena bīstamās zonās. Ja mērīšanas ķēde jāuzstāda sprādzienbīstamā zonâ, ir jāievēro lietošanas instrukcijā dotie instalēšanas norādījumi. Ja rodas kādas valodas grūtības, lūdzu griezieties pie izgatavotāja firmas, kas Jums nosūtīs nozīmīgâko nodaļu tulkojumus lietotāja valsts valodā. Emerson epro GmbH Jöbkesweg 3 48599 Gronau...

  • Page 5: Table Of Contents

    4.6 Recommended sequence for installing the AMS Asset Monitor............30 4.7 Mount the AMS Asset Monitor......................31 4.8 Mount the AMS Asset Monitor by using the universal mounting bracket.........31 4.9 Replace the cable inlet dust caps....................35 4.10 Grounding............................ 36 4.11 Network connection........................38...
  • Page 6 Contents Installation Guide March 2024 MHM-97923-PBF 5.1.1 Connect the power supply......................46 5.2 Install a VI Piezo CHARM......................... 46 5.2.1 Connect the sensor wiring......................47 5.3 Install a VI Tach CHARM........................48 5.3.1 Connect the sensor wiring......................49 5.4 Install a VI Voltage CHARM......................52 5.4.1 Connect the voltage input wiring....................
  • Page 7 9.1 Connections and interfaces......................81 9.2 Indications and buttons........................82 9.3 Slots............................... 82 9.4 Dimensions and electrical data – AMS Asset Monitor..............82 9.5 Dimensions and electrical data – +24 V DC Power Module..............83 9.6 Environmental conditions – AMS Asset Monitor................84 9.7 Environmental conditions –...

  • Page 8: Chapter 1 General

    AMS Asset Monitor hardware. Read this guide completely prior to starting installation of the device. Comply with all safety instructions. This installation guides applies for an AMS Asset Monitor with a hardware revision listed in Table 1-1. See type plate for revision level.

  • Page 9: Symbols

    Installation Guide General MHM-97923-PBF March 2024 Table 1-3: Product type and ordering numbers of AMS Asset Monitor and compatible DeltaV hardware Hardware Product type number Ordering number AMS Asset Monitor AM 5820-IM SE8701T01-IM AMS Asset Monitor – Marine AM 5820-IM BL...

  • Page 10: Liability And Guarantee

    Liability and guarantee Emerson is not liable for damages that occur due to improper use. Proper use also includes the knowledge of, and compliance with, this document. Customer changes to the device that have not been expressly approved by Emerson will result in the loss of guarantee.

  • Page 11: Storage And Transport

    March 2024 +63 2 8702 1111 (Asia Pacific, Europe, and Middle East) Email Guardian.GSC@Emerson.com http://www.emerson.com/en-us/contact-us To search for documentation, visit http://www.emerson.com. To view toll free numbers for specific countries, visit http://www.emerson.com/ technicalsupport. Note If the equipment has been exposed to a hazardous substance, a Material Safety Data Sheet (MSDS) must be included with the returned materials.

  • Page 12: Ccc Certification - Ams Asset Monitor

    The names and contents of hazardous substances can be found in chapter "Certificates". CCC Certification – AMS Asset Monitor With the announcement of the Chinese market regulation authority SAMR (State Administration for Market Regulation), a Compulsory Product Certification (CCC certification) is mandatory for many explosion protection products.

  • Page 13: Chapter 2 Safety Instructions

    Installation Guide Safety instructions MHM-97923-PBF March 2024 Safety instructions To ensure safe operation, carefully follow all the instructions in this manual. The correct and safe use of this device requires that operating and service personnel both understand and comply with general safety guidelines and observe the special safety comments listed in this manual.

  • Page 14: Esd Safety

    Safety instructions Installation Guide March 2024 MHM-97923-PBF ESD safety DANGER Internal components can be damaged or destroyed due to electrostatic discharge (ESD) during the handling of the device. Take suitable precautions before handling the device to prevent electrostatic discharges through the electronics. Such measures might include, for example, wearing an ESD bracelet.

  • Page 15: Planning The Installation

    Voltmeter To check the supply voltage and the connected signals. Torque limits for mounting screws Table 3-1 lists the permissible maximum torque limits for the screws of the AMS Asset Monitor hardware. Table 3-1: Maximum torque limits Hardware part Maximum torque limit Power supply terminal screws 0.5 Nm...

  • Page 16: Wiring Guidelines

    Separate AC voltage circuits from low voltage signals to comply with safety recommendations and to mitigate induced noise in the signals. This good practice is recommended by Emerson although any signal type can be installed in any CHARM slot of the AMS Asset Monitor.

  • Page 17: Wiring Overview

    CHARM Terminal Blocks Conductor cross section AWG (stranded or solid) The recommended stripping length of the wires is 10 mm. 3.3.1 Wiring overview Figure 3-1 for an example overview of a standard wiring of an AMS Asset Monitor. MHM-97923-PBF, Rev. 2.10...
  • Page 18 MHM-97923-PBF Figure 3-1: Wiring overview A. Connection to protective ground, see Grounding B. 24 V DC power supply for the AMS Asset Monitor, see Connect the power supply C. Connection VI Piezo CHARM, see Connect the sensor wiring D. Connection analog input AI 4-20 mA CHARM, see Connect the input signal wiring –...

  • Page 19: Select A Mounting Place

    Place the AMS Asset Monitor on a higher level than sensors installed in the machine to prevent oil from entering the AMS Asset Monitor through the cables. • Place the AMS Asset Monitor so that all cables can be led through the cable glands at the bottom of the AMS Asset Monitor. •...

  • Page 20: Installing Ams Asset Monitor Hardware

    • The sum of the load current of the outputs of all Discrete Output CHARMs (KL3002X1- BA1) installed in the AMS Asset Monitor must not exceed 1200 mA, each output must not exceed 100 mA. About the AMS Asset Monitor hardware...
  • Page 21 Cable glands, suitable for the environmental conditions on-site • Address plug with suitable terminal block The AMS Asset Monitor supports the VI Piezo CHARM, the VI Voltage CHARM, the VI Tach CHARM, and the DeltaV hardware listed in Table 4-1.
  • Page 22 The AMS Asset Monitor has cable entries with 1/2-NPT cable gland threading. Note The AMS Asset Monitor is shipped with dust protective caps in the cable inlets. These red colored caps are only to protect the inner parts of the AMS Asset Monitor during transport.
  • Page 23 Installation Guide Installing AMS Asset Monitor hardware MHM-97923-PBF March 2024 Figure 4-1: Overview – AMS Asset Monitor A. Status light (if several notifications are present, always the worst is indicated) B. Door C. Screws for securing the door D. Base E.
  • Page 24 Installing AMS Asset Monitor hardware Installation Guide March 2024 MHM-97923-PBF Figure 4-2: Overview – rear side AMS Asset Monitor A. Mounting holes B. Pressure compensation vent C. Blind mounting holes with standard M8x1.25 thread MHM-97923-PBF, Rev. 2.10...
  • Page 25 +24 V DC Power Module The +24 V DC Power Module is used to supply the AMS Asset Monitor including all installed CHARMs. Because of the possible network traffic, Emerson recommends to daisy chain no more than eight AMS Asset Monitors. MHM-97923-PBF, Rev. 2.10...

  • Page 26: Position Of The Mounting Holes

    Position of the mounting holes The AMS Asset Monitor has four through holes without thread and four blind holes with a standard M8 thread to mount the AMS Asset Monitor on a flat surface like a wall or on a framework.
  • Page 27 Installation Guide Installing AMS Asset Monitor hardware MHM-97923-PBF March 2024 Figure 4-5: Position of the four through holes for mounting A. 196 mm B. 6.5 mm C. 330 mm MHM-97923-PBF, Rev. 2.10...

  • Page 28: Open The Ams Asset Monitor

    C. Blind hole with M8x1.25 thread; depth: 20 mm, threaded depth: 16 mm Open the AMS Asset Monitor All work at the AMS Asset Monitor requires an open door. If the door hinders you from working at the AMS Asset Monitor, it can be completely removed.
  • Page 29 Figure 4-7: Position of the screws A. Screws for securing the door. 2. Swivel the door to the left to open the AMS Asset Monitor. 3. To remove the door completely, remove the circlip that secures the door from unintentional removal.

  • Page 30: Close The Ams Asset Monitor

    Recommended sequence for installing the AMS Asset Monitor The described installation sequence is a recommendation and can be changed to the needs of your project. Procedure 1. Remove the door of the AMS Asset Monitor. 2. Mount the AMS Asset Monitor. MHM-97923-PBF, Rev. 2.10...

  • Page 31: Mount The Ams Asset Monitor

    11. Reattach the door. Mount the AMS Asset Monitor Prerequisites You need two people to lift the AMS Asset Monitor and fix it on the mounting place. Procedure 1. Remove the door of the AMS Asset Monitor. See Open the AMS Asset Monitor.
  • Page 32 Installing AMS Asset Monitor hardware Installation Guide March 2024 MHM-97923-PBF Figure 4-10: Universal mounting bracket A. Plate B. Post C. Clamping jaws D. Bolts with nuts MHM-97923-PBF, Rev. 2.10...
  • Page 33 March 2024 Figure 4-11: Universal mounting bracket – vertical mounting A. M8 x 1.25 x 18 mm hex head bolt (4x) for mounting the plate on the back of the AMS Asset Monitor B. M8 x 1.25 hex nut (4x) for fastening the clamping jaws C.
  • Page 34 D. M8 split lock washer (12x) E. M8 x 1.25 x 120 mm hex head bolt for fastening the clamping jaws F. M8 x 1.25 x 18 mm hex head bolt (4x) for mounting the plate on the back of the AMS Asset Monitor Note Ensure that the post can permanently bear the weight of the AMS Asset Monitor.

  • Page 35: Replace The Cable Inlet Dust Caps

    8. Tighten the bolts to fix the AMS Asset Monitor on the mounting bracket. Replace the cable inlet dust caps The AMS Asset Monitor is shipped with dust protective caps in the cable inlets. These red colored caps are only to protect the inner parts of the AMS Asset Monitor during transport.

  • Page 36: Grounding

    Press the caps out from the inside or use a pair of pliers to pull them out. 2. Screw the required cable glands into the cable inlets. Ensure proper sealing of the cable glands to keep the IP protection of the AMS Asset Monitor. See documentation of the used cable glands for details.
  • Page 37 Installation Guide Installing AMS Asset Monitor hardware MHM-97923-PBF March 2024 Figure 4-14: Ground connection A. Grounding terminals for connecting the shields of the sensor or signal field cables B. Shield of the field cable C. Labeled internal grounding terminal D. Internal grounding terminal E.

  • Page 38: Network Connection

    There may be exceptions to this recommendation. 4.11 Network connection The AMS Asset Monitor is equipped with a RJ-45 Ethernet socket with a speed of 1 Gbit/s (LAN1) for configuration and connection to subsequent systems such as AMS Machine Works or Plantweb Optics.
  • Page 39 D. Clients with AMS Machine Works Vibration Analyzer E. Switch F. AMS Asset Monitors G. LAN1 Vibration Analyzer clients can be installed on the same networks level as the AMS Machine Works Server or one network level higher. MHM-97923-PBF, Rev. 2.10...
  • Page 40 CAT 5(e) or higher Ethernet cable • Maximum Ethernet cable length between devices is 100 meters. Vibration Analyzer clients can be installed on the same networks level as the AMS Machine Works Server or one network level higher. MHM-97923-PBF, Rev. 2.10...
  • Page 41 Follow the steps to connect an Ethernet cable: Procedure 1. Lead the Ethernet cable through a suitable cable gland at the bottom of the AMS Asset Monitor. 2. Strip the Ethernet cable in accordance to the needs of the RJ 45 plug.

  • Page 42: Installing Charms Hardware

    This section describes the general CHARM installation. The CHARMs together with their required CHARM Terminal Blocks can be installed in any arbitrary slot of the AMS Asset Monitor. You can mix and match the CHARMs and their Terminal Blocks in any order on the baseplate.
  • Page 43 Installation Guide Installing CHARMs hardware MHM-97923-PBF March 2024 Figure 5-2: CHARM Terminal Block installation The CHARM Terminal Block locks with an audible click. 5. Ensure that the latch of the CHARM Terminal Block is in the open position. If the latch is in the closed position, move it outwards to open it.
  • Page 44 7. Wire the CHARM Terminal Block according to the requirements of the installed CHARM. 8. Label the installed CHARM. See Label the installed CHARMs. 9. Continue with the installation work or close the door (see Close the AMS Asset Monitor). MHM-97923-PBF, Rev. 2.10...

  • Page 45: Install The +24 V Dc Power Module

    Install the +24 V DC Power Module CAUTION Any work on the system may impair asset health monitoring and machine protection. Procedure 1. Open the AMS Asset Monitor (see Open the AMS Asset Monitor), if not already done. 2. Ensure that the latch is in open position as shown in Figure 5-5.

  • Page 46: Connect The Power Supply

    Connect a +24 V DC power supply to the power supply terminals of the AMS Asset Monitor. Connect the +24 V DC of the power supply to the + terminal of the AMS Asset Monitor and GND of the power supply to the - terminal.

  • Page 47: Connect The Sensor Wiring

    Installation Guide Installing CHARMs hardware MHM-97923-PBF March 2024 5.2.1 Connect the sensor wiring Figure 5-7: Sensor connection A. VI Piezo CHARM B. CHARM Baseplate C. CHARM Terminal Block D. 2-wire piezoelectric or strain sensor E. Cable shield connection F. Top view of the sensor connector – terminal A G.

  • Page 48: Install A Vi Tach Charm

    The VI Tach CHARM is designed for the connection of magnetic pickups, output signals of eddy current measurement chains, and Hall-effect sensors. The VI Tach CHARM is supplied by the AMS Asset Monitor. A CHARM Terminal Block is required for the installation. See installation guide of the VI Tach CHARM for further details. See...

  • Page 49: Connect The Sensor Wiring

    Installation Guide Installing CHARMs hardware MHM-97923-PBF March 2024 5.3.1 Connect the sensor wiring Figure 5-8: Sensor connection – magnetic pickup A. VI Tach CHARM B. CHARM Baseplate C. Standard CHARM Terminal Block D. Signal Out E. Signal GND F. Magnetic pickup G.
  • Page 50 Installing CHARMs hardware Installation Guide March 2024 MHM-97923-PBF Figure 5-9: Sensor connection – output signal of an eddy current measuring chain A. VI Tach CHARM B. CHARM Baseplate C. Standard CHARM Terminal Block D. Signal GND E. Signal OUT F. External power supply for the eddy current measuring chain G.
  • Page 51 Installation Guide Installing CHARMs hardware MHM-97923-PBF March 2024 Figure 5-10: Sensor connection – Hall-effect sensor A. VI Tach CHARM B. CHARM Baseplate C. Standard CHARM Terminal Block D. GND E. Signal output F. +24 V power supply G. Cable shield connection H.

  • Page 52: Install A Vi Voltage Charm

    The VI Voltage CHARM is designed for the connection of voltage signals in the range of -24 V to +24 V. The VI Voltage CHARM is supplied by the AMS Asset Monitor. A CHARM Terminal Block is required for the installation. See installation guide of the VI Voltage CHARM for further details.

  • Page 53: Connect The Voltage Input Wiring

    Installation Guide Installing CHARMs hardware MHM-97923-PBF March 2024 5.4.1 Connect the voltage input wiring Figure 5-11: Signal connection A. VI Voltage CHARM B. CHARM Baseplate C. Standard CHARM Terminal Block D. Cable shield connection E. Signal F. Return G. Voltage signal source Prerequisites •...

  • Page 54: Install A Do 24 V Dc High-Side Charm

    The DO 24 V DC High-Side CHARM is a discrete output CHARM for momentary output signals or continuous pulse outputs. The CHARM is supplied by the AMS Asset Monitor. A CHARM Terminal Block is required for the installation. If a relay output is required use the CHARM Relay Output Terminal Block.

  • Page 55: Connect The Output Signal Wiring

    Installation Guide Installing CHARMs hardware MHM-97923-PBF March 2024 5.5.1 Connect the output signal wiring Figure 5-12: Signal connection A. Digital Output DO 24 V DC High-Side CHARM B. CHARM Baseplate C. CHARM Terminal Block D. Field device with digital input E.

  • Page 56: Connect The Relay Output Wiring

    Connect the cable shield to a grounding terminal (see Grounding). 5. Ensure that the cable gland, where the signal cable is led through, is closed to keep the IP protection class of the AMS Asset Monitor. 6. Continue with the installation or close the door (see Close the AMS Asset Monitor).

  • Page 57: Install A Di 24 V Dc Low-Side Sens Charm

    Install a DI 24 V DC Low-Side Sens CHARM The DI 24 V DC Low-Side Sens CHARM is a discrete input CHARM for sensing relay and switch contact closure. The CHARM is supplied by the AMS Asset Monitor. A CHARM Terminal Block is required for the installation. See...

  • Page 58: Connect The Input Signal Wiring

    Installing CHARMs hardware Installation Guide March 2024 MHM-97923-PBF 5.6.1 Connect the input signal wiring Figure 5-14: Signal connection A. Digital Input DI 24 V DC Low-Side Sense (dry contact) CHARM B. CHARM Baseplate C. CHARM Terminal Block D. Field device with digital output E.

  • Page 59: Install A Ai 4 To 20 Ma Charm

    The AI 4 to 20 mA CHARM is an analog input CHARM for 4 to 20 mA signals. The CHARM is supplied by the AMS Asset Monitor. A CHARM Terminal Block is required for the installation. Self-powered or loop-powered field devices with an analog output can be connected.

  • Page 60: Connect The Input Signal Wiring - Self-Powered

    Installing CHARMs hardware Installation Guide March 2024 MHM-97923-PBF 5.7.1 Connect the input signal wiring – self-powered Figure 5-15: Signal connection A. Analog Input AI 4 to 20 mA CHARM B. CHARM Baseplate C. CHARM Terminal Block D. Field device with analog output E.

  • Page 61: Connect The Input Signal Wiring - Loop-Powered

    Connect the cable shield to a grounding terminal (see Grounding). 5. Ensure that the cable gland, where the signal cable is led through, is closed to keep the IP protection class of the AMS Asset Monitor. 6. Continue with the installation or close the door (see Close the AMS Asset Monitor).

  • Page 62: Install A Rtd Charm

    Monitor). Install a RTD CHARM The RTD CHARM is a CHARM for temperature measurement with RTD sensors. The CHARM is supplied by the AMS Asset Monitor. A CHARM Terminal Block is required for the installation. See Installing CHARMs hardware for the general CHARM installation procedure.

  • Page 63: Connect The Sensor Wiring

    Installation Guide Installing CHARMs hardware MHM-97923-PBF March 2024 5.8.1 Connect the sensor wiring Figure 5-17: Sensor connection A. RTD CHARM B. CHARM Baseplate C. CHARM Terminal Block D. 4-wire RTD E. Cable shield connection F. 3-wire RTD G. 2-wire RTD Prerequisites •...

  • Page 64: Install A Thermocouple/Mv Input Charm

    Monitor). Install a Thermocouple/mV input CHARM The Thermocouple/mV input CHARM is a CHARM for temperature measurement with thermocouples. The CHARM is supplied by the AMS Asset Monitor. A CHARM Thermocouple/mV Terminal Block is required for the installation. See Installing CHARMs hardware for the general CHARM installation procedure.

  • Page 65: Connect The Sensor Wiring

    Installation Guide Installing CHARMs hardware MHM-97923-PBF March 2024 5.9.1 Connect the sensor wiring Figure 5-18: Sensor connection A. Thermocouple CHARM B. CHARM Baseplate C. CHARM Thermocouple /mV Terminal Block D. Internal RTD E. Cable shield connection Prerequisites • Wire cutter •...

  • Page 66: Install The Address Plug

    5.10 Install the Address Plug The AMS Asset Monitor is equipped with a dedicated slot for an Address Plug. The Address Plug is required for proper function of the installed CHARMs. A CHARM Address Terminal Block is required for the installation. See the documentation provided with the Address Plug and the Address Terminal Block for further details.

  • Page 67: Label The Installed Charms

    Label the installed CHARMs The CHARM labeling component consists of a label support that holds a label and its protective plastic cover. Remove the label support from the AMS Asset Monitor before writing or typing the CHARM IDs on the label.
  • Page 68 Installing CHARMs hardware Installation Guide March 2024 MHM-97923-PBF Figure 5-21: CHARM labeling component A. Baseplate B. Protective cover C. Label D. Label support E. Hinge Procedure 1. Press the label support at the top hinge and remove it from the hinge post. 2.

  • Page 69: Charm Protection Cover

    Installation Guide Installing CHARMs hardware MHM-97923-PBF March 2024 5.12 CHARM Protection Cover Use the CHARM Protection Cover to protect unused CHARM Terminal Blocks from damage. The CHARM Protection Cover does not affect the key setting on the CHARM Terminal Block. See documentation provided with the Protection Cover for installation and further details.

  • Page 70: Removing Charms Hardware

    March 2024 MHM-97923-PBF Removing CHARMs hardware Follow these steps to remove CHARMs hardware from the AMS Asset Monitor. Note CHARMs and Terminal Blocks are hot-swappable. It is not necessary to switch off the system's power supply before installing or removing CHARMs or Terminal Blocks.

  • Page 71: Remove A Terminal Block

    Installation Guide Removing CHARMs hardware MHM-97923-PBF March 2024 Remove a Terminal Block Follow these steps to remove a CHARM (Standard), Thermocouple/mV, Address, or Relay Output Terminal Block. Prerequisites • Suitable flat-tip screwdriver to unlock the Terminal Block. • Suitable flat-tip screwdriver for the terminal screws. DANGER Ensure that no device, such as a CHARM or an Address Plug, is installed in the Terminal Block to be removed.

  • Page 72: Remove The Address Plug

    Removing CHARMs hardware Installation Guide March 2024 MHM-97923-PBF 7. Emerson recommends resetting the keying posts of removed CHARM Terminal Blocks to prepare it for the installation of other CHARM types. For resetting the key settings see Installing CHARMs hardware. The Thermocouple/mV Terminal Block has a fixed key setting and cannot be reset.

  • Page 73: Hazardous Location Installation

    Version 2.1 General installation requirements The AMS Asset Monitor must be solely connected to SELV/PELV electrical circuits to meet the requirements for explosion protection. This also applies to all devices connected to the AMS Asset Monitor. Exceptions are explicitly stated. In version 1.0, the Relay Terminal Block is approved for voltages up to 250 V.

  • Page 74: Technical Data, Explosion Protection

    AVERTISSEMENT: NE PAS OUVRIR DANS UNE ZONE À RISQUE D’EXPLOSION DE POUSSIÈRES Technical data, explosion protection The AMS Asset Monitor is checked and certified for the following, if connected to SELV/ PELV – electrical circuits for use in potentially explosive atmospheres: IECEx/ATEX/CSA...

  • Page 75: Revision History

    Installation Guide Hazardous location installation MHM-97923-PBF March 2024 IECEx/ATEX/CSA ATEX EN IEC 60079-0:2018 EN IEC 60079-7:2015/A1:2018 EN 60079-11:2012 EN 60079-15:2010 EN 60079-31:2014 CAN/CSA-C22.2 No. 0-10 CAN/CSA-C22.2 No. 61010-1:12 + Amd 1-18 CAN/CSA C22.2 No. 94.2-15 CAN/CSA-C22.2 No. 60079-0:15 CAN/CSA C22.2 No. 60079-0:19 CAN/CSA-C22.2 No.

  • Page 76: Maintenance, Troubleshooting, Replacement And Repair

    Maintenance The AMS Asset Monitor does not require any maintenance during normal operation. Troubleshooting Follow these first troubleshooting steps in case of an unexpected behavior of an AMS Asset Monitor. Procedure 1. Connect your configuration device to the suspicious AMS Asset Monitor and open AMS Asset Monitor Web Interface.

  • Page 77: Replacement And Repair

    At least one of the installed CHARMs is disabled. Replacement and repair In case of a defect, several components of the AMS Asset Monitor can be replaced on-site. It is not possible to repair defective CHARMs, +24 V DC Power Modules, and AMS Asset Monitors.

  • Page 78: Replace A Defective Charm

    Installing CHARMs hardware for details. 4. Switch the power supply of the AMS Asset Monitor on – if not already be done. 5. Check the operational readiness to complete the replacement of the CHARM. The status LED of the CHARM lights solid green if no fault is detected.
  • Page 79 Procedure 1. Open the door of the AMS Asset Monitor. 2. Create a backup file of the AMS Asset Monitor, if possible. See AMS Asset Monitor operating manual. a) Connect the configuration device through the RJ 45 Ethernet connector to the AMS Asset Monitor.
  • Page 80 If it was not possible to create a backup file or if no back-up file, created before, is available create a new configuration. 16. Check the operational readiness to complete the replacement of the AMS Asset Monitor. The status LED of all installed CHARMs light solid green if no fault is detected.

  • Page 81: Technical Data

    Installation Guide Technical data MHM-97923-PBF March 2024 Technical data Only specifications with indicated tolerances or limit values are obligatory. Data without tolerances or without error limits are informative data and not guaranteed. Technology is under constant development, and specifications are subject to change without notice. If not otherwise specified, all data refer to a nominal supply voltage of +24 V DC and an environmental temperature of +23°C .

  • Page 82: Indications And Buttons

    VI Tach CHARM AM 5312 Address plug Plug 1 Installation requires Address Terminal Block No HART support. Dimensions and electrical data – AMS Asset Monitor Electrical data Power dissipation <15 W Exclusive feed through power Overvoltage category MHM-97923-PBF, Rev. 2.10...

  • Page 83: Dimensions And Electrical Data - +24 V Dc Power Module

    Installation Guide Technical data MHM-97923-PBF March 2024 Mechanical data Dimensions Figure 9-1 Weight <7000 g Without packaging, +24 V DC Power Module, and all other installable parts Figure 9-1: Dimensions A. 384 mm B. 75 mm C. 123 mm D. 241 mm Dimensions and electrical data –...

  • Page 84: Environmental Conditions - Ams Asset Monitor

    Status indication Green power LED Red error LED Figure 9-2: Dimensions A. 25 mm B. 95 mm C. 113 mm Environmental conditions – AMS Asset Monitor Operating temperature -40 to +55°C Storage temperature -40 to +85°C Humidity 5 to 95%...

  • Page 85: Environmental Conditions - +24 V Dc Power Module

    Operating altitude <2000 m Above sea level Allowed degree of pollution Internal. Ensure that no water or dirt gets into the AMS Asset Monitor when it is open. Environmental conditions – +24 V DC Power Module Operating temperature -40 to +70°C Storage temperature -40 to +85°C...

  • Page 86: Chapter 10 Certificates

    Certificates Installation Guide March 2024 MHM-97923-PBF Certificates MHM-97923-PBF, Rev. 2.10...
  • Page 87 Installation Guide Certificates MHM-97923-PBF March 2024 MHM-97923-PBF, Rev. 2.10...
  • Page 88 Certificates Installation Guide March 2024 MHM-97923-PBF MHM-97923-PBF, Rev. 2.10...
  • Page 89 Installation Guide Certificates MHM-97923-PBF March 2024 MHM-97923-PBF, Rev. 2.10...
  • Page 90 Certificates Installation Guide March 2024 MHM-97923-PBF MHM-97923-PBF, Rev. 2.10...
  • Page 91 Installation Guide Certificates MHM-97923-PBF March 2024 MHM-97923-PBF, Rev. 2.10...
  • Page 92 Certificates Installation Guide March 2024 MHM-97923-PBF MHM-97923-PBF, Rev. 2.10...

  • Page 93: Index

    Installation Guide Index MHM-97923-PBF March 2024 Index Numerics 2-wire piezoelectric sensor 46, Keying post CCC Certification Maintenance CHARM microSD Card Address Plug 20, Mounting holes 24, Address Terminal Screw Block 20, Mounting place AI 4 to 20 mA 20, 60, AO 4 to 20 mA DI 24 V Low-Side Sens (dry contact) 20, DO 24 V High-Side 20, 55,...
  • Page 94 Index Installation Guide March 2024 MHM-97923-PBF Wire-cross section Wiring Analog input Digital input Digital output Piezoelectric sensor Power supply Thermocouple VI Tach CHARM VI Voltage CHARM Wiring, RTD MHM-97923-PBF, Rev. 2.10...
  • Page 95 Installation Guide MHM-97923-PBF March 2024 MHM-97923-PBF, Rev. 2.10...
  • Page 96 The Emerson logo is a trademark and service mark of Emerson Electric Co. The AMS logo is a mark of one of the Emerson family of companies. All other marks are the property of their respective owners.
