Monitor Articulated Arm for Camera Cart

(VCTR-MA)

A s s e m b l y M a n u a l

What's In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

VESA Mount With Mounting Arm

2 x Rods

2 X L-Type Allen Keys

2 X Pair Monitor Arm Clamps

(Size: 4mm, 3/16")

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright

statutes or in writing by the Publisher.

Need help?

Do you have a question about the CINEMA Series and is the answer not in the manual?

Page 1 Monitor Articulated Arm for Camera Cart (VCTR-MA) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Page 2 Monitor Articulated Arm Setup Monitor Arm Clamp Mounting • Loosen the ratchet knob and open the clamp. • Align and attach the clamp to the rod and securely tighten it using the ratchet knob. • Similarly, attach the other clamp to the rod as shown in the image.
Page 3 • Insert the rod into the clamp holes. • After inserting the rod, tighten the knobs of both clamps to secure it. • The Rod is securely attached to the clamps. Adjustable Arm Mounting • Open the Adjustable Arm. • Loosen the knob of the Adjustable Arm.
Page 4 • The Adjustable Arm is securely mounted on the rod. LCD Monitor Mounting • Loosen the grub screw using a 3/16" Allen key. • Now detach the VESA Mount. • Place the VESA Mount on the back of the LCD monitor (Not Included) by aligning it with the...
Page 5 • Now, securely tighten the grub screw using a 3/16" Allen key. YOUR PROAIM MONITOR ARTICULATED ARM FOR CAMERA CART ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer a one-year warranty for our products from the date of purchase. Within this period, we will repair it without charge for labor or parts.
