Nidec PG-20 Instruction Manual

Thin film type semiconductor pressure gauge
PG-20
CE marking
（Compliance with EMC Standards）
Instruction Manual
Important Information and Warnings
These products (pressure sensors, pressure switches, pressure gauges, pressure indicators, leakage sensors, etc.) are designed and manufactured as
general industrial parts. Therefore, a person with sufficient knowledge and experience shall confirm the conditions and environments described in the
catalog, specifications, and instruction manual of each product, check the suitability of the product for the machine, device, or system which you
use, and ensure safety before use.
These products are not intended to be used for applications particularly requiring high reliability (These include, but are not limited to, nuclear power control,
aerospace and military purposes).
The details of warranty shall be as per the descriptions in this document and we shall not be liable for any damage on you resulting from the use of any
equipment or device (including control systems) which is not in accordance with this document (hereinafter referred to as "use in violation"). In the case where
you resell our products, we shall not be liable for any damage on a third party resulting from use in violation by the third party, and even if we make payment
to the third party in connection with such use in violation regardless of the name by which such payment may be called, we may demand the whole amount
thereof from you.
① The applicatable pressure medium of PG-20 gases and liquids compatible to SUS316L.
② For stability, use a regulated direct current power supply.
Please earth the terminal FG when you use the switching power supply.
③ Surge absorbing devices（diodes, varistors, etc.）are necessary if inductive loads such as relays or solenoids are connected to the same circuit to PG-20.
④ Turn off the power while wiring. Also, please do not mis-wire.
⑤ Do not wire parallel to a high tension cables or power lines, or use cable ducts containing high tension or high power.
⑥ Cables connectors should be removed from the product while piping. The product can be damaged if the connected cable is pulled at 20N or more. In
addition, the display rotation part can be damaged when turning the display at 0.3N・m or more.
⑦ Clean the product with the cloth that contains a small amount of pure water or alcohols solvent when the product is dirty. The cleaning solution must
never enter into the product. It may cause an internal circuit breakdown.
⑧ This product is dust proof and drip proof（to IP40 of IEC standards）and is not suitable for use in environments requiring higher standards.
⑨ Do not use pointed objects such as pens to press the setting buttons on the display panel, as this may push holes in the setting buttons and damage
them.
⑩ Do not insert wires, etc. in the pressure port, as this may damage the internal diaphragm and cause malfunctioning.
⑪ Do not touch or scratch the edge of the fitting, as this may damage the sealing and cause leakage.
⑫ The PG-20 series is not explosion proof. Do not use it for the detection of flammable gases.
⑬ When analog output is supplied to a noise-sensitive device, a low-pass filter is requested in a customer's circuit.
⑭ For EMC measures, please earth the power supply. Also, please connect the fitting block to an earthed metalic casing or to the ground. This product can
not resist thunder surge, therefore please do not use this product at unprotected outdoors or extend the cable to 30m or more.
Thank you for purchasing a
NIDEC COMPONENTS CORP. product.
In order to use the product correctly and most
appropriately, please completely read this manual before
use and keep it for future reference.
Ver.3.0
For more detailed information please ask for the
nearest distributor or the following sales center.
Nishi-Shinjuku Prime Square bldg., 7-5-25
Nishi-Shinjuku, Shinjuku-ku,Tokyo 160-0023, Japan
Phone: +81-3-3364-7055 Fax: +81-3-3364-7098
URL ： https://www.nidec-components.com
