Force On/Off; Displaying List Of Forced-On/Off Bits - Omron CX-PROGRAMMER - INTRODUCTION GUIDE Introduction Manual

Online
Online
to Transfer
to Transfer
Move the cursor to a
contact or coil that you
want to force on/off.
Click the right mouse
Click the right mouse
button. ->
button. ->
[Force] -> [On]
[Force] -> [On]
Force Off/Cancel of
Force Off/Cancel of
bits/coils are enabled
bits/coils are enabled
in the same way.
in the same way.
Shortcut Key
Shortcut Key
Ctrl+J: Force On
Ctrl+J: Force On
Ctrl+K: Force Off
Ctrl+K: Force Off
Display Project
Workspace.
[Alt] + 1
Double-click
[Memory].
Click the
[Address] tab.
Double-click
[Forced Status].
Monitoring
Monitoring
Contacts/coils are forced on/off from CX-Programmer.
Once bits/coils are forced on/off, the forced statuses are held until cancelled or the
reverse procedures of on/off are taken.
The statuses do not change by an external input or the operational result of the
program.
Moreover, force operations are not enabled when the PLC is in the Run mode.

13. Displaying List of Forced-on/off Bits

The bits forced on/off can be listed in a table.
This function enables you to check the forced statuses of more than one bit at a glance.
Force On
Force On
Force Off
Force Off

12. Force On/Off

mark indicates that the bit is
now being forced on/off.
