Monitoring - 4 Watch Window - Omron CX-PROGRAMMER - INTRODUCTION GUIDE Introduction Manual

Online
Online
to Transfer
to Transfer
Display Watch
Window.
Alt 3
Enter a bit number
that you want to
monitor.
400
ENT
Press the ENT key
continuously for auto
increment of addresses.
ENT
ENT
ENT
Entry of BOOL type (contact)
Entry of BOOL type (contact)
Monitoring
Monitoring

6. Monitoring - 4 Watch Window

I/O monitoring of the addresses specified in Watch Window is executed.
Example: Entry of 4CH 00Bit
Force On
Force On
Force Off
Force Off
The addresses registered in Watch Window are still stored
when CX-Programmer is opened next time.
Enter "." (period) between CH and Bit.
Enter "." (period) between CH and Bit.
Or enter "400" without a period in the "Name or
Or enter "400" without a period in the "Name or
address" box and then specify "BOOL" in the "Data
address" box and then specify "BOOL" in the "Data
Type/Format" box (Reverse the box and then press B
Type/Format" box (Reverse the box and then press B
key form the keyboard.)
key form the keyboard.)
Program
Program
Check
Check
You can also enter a given
You can also enter a given
address in this status.
address in this status.
Online
Online
Edit
Edit
