Installation
Installation
to Startup
to Startup
Move the cursor to this
position. (The rung is
inverted in blue.)
ENT
[Process_at_Startup]
Enter a rung comment.
ENT
/
1
ENT
Sensor 1
ENT
Opening a
Opening a
new project
new project

5-4. Entry of Rung Comment

The entry screen
shows up.

5-5. Entry of Normally Closed Contact

Press "/" from a keyboard to show the [New Closed Contact] dialog.
Device type
Device type
settings
settings
Creating a
Creating a
program
program
