Online

to Transfer

(5)Then retrace rungs to find a cause from the contact 1.01. As well as the operations

Space

(6)The focus moves to the coil 1.01. As it turned out, the cause was the contact 0.01

Press the [Space] key to jump from a coil to a contact having the same address as the

coil or from a contact to a coil in reverse.

Press the [N] key for another jump from a contact or coil at the cursor position to a next

one having the same address.

To move back to the position of the last jump, press the [B] key.

This is a useful function available in SYSMAC Support Software.

CX-Programmer inherits it.

Monitoring

so far, move the cursor to the contact 1.01 and press the [Space] key.

that was not turned on.

Force On

Force Off

Program

Check

Online

Edit
