2. List of Software to be Installed

2. List of Software to be Installed
CX-One Support Software installed with CX-One is shown below.
CX-One Support Description
Software
CX-Programmer Software to create and debug programs for SYSMAC CS/CJ series,
C series, or CVM1/C series.
CX-Integrator Software to start up and configure FA networks such as Controller
Link, DeviceNet, and CompoWay/F.
CX-Position Software to create and monitor various data for SYSMAC CS/CJ
series NC Unit.
CX-Motion Software to create various data for MC Unit of SYSMAC CS/CJ
series, alpha series, and CV series and to create and monitor MC
programs.
CX-Motion-NCF Software to create and monitor various data for SYSMAC CS/CJ
series NCF Unit.
CX-Motion-MCH Software to create various data, motion programs and monitor the
SYSMAC CS/CJ series MCH Unit.
CX-Drive Software to configure and adjust various inverter servo data.
CX-Designer Software to create screen data for programmable terminal NS series.
CX-Process Software to create and debug instrument block programs for loop
Tool control Unit board, process, and loop CPU Unit of SYSMAC CS/CJ
series.
Face Plate
Software to automatically generate NS series project files for
Auto-Builder
monitoring and tuning of a loop controller.
for NS
CX-Protocol Software to create data transmission procedure (protocol) with an
external universal device that is connected to a serial
communications board/Unit of SYSMAC CS/CJ series and SYSMAC
alpha series.
CX-Profibus Software to configure the PROFIBUS Master.
(Possible to install Windows NT4.0/2000/XP only.)
CX-Simulator Software to debug programs for SYSMAC CS/CJ series without the
CPU Unit by simulating the CPU operation on a personal computer.
CX-Thermo Software to configure and adjust parameters for devices
(Components such as temperature controller).
(Possible to install Windows 2000/XP only.)
CX-FLnet Software to configure and monitor the SYSMAC CS/CJ series FLnet
Unit.
Switch Box Utility software to support PLC debugging. Input/output status and
Utility current values of address in a user-specified PLC can be monitored
and modified easily.
PLC Support A group of Components that are commonly used by software that
Software consists CX-One, such as CX-Programmer and CX-Integrator.
CX-Server Middleware required for communications between CX-One Support
Software and OMRON's Components such as PLC, indicator, or
temperature controller.
About 1.8GB of free hard drive space is required on your personal computer to install all CX-One Support
Software.
Make sure that sufficient free space is available.
Required free Remarks
space on
hard drive
ca. 250MB If necessary
ca. 100MB
ca. 15MB
ca. 40MB
ca. 100MB
ca. 100MB
ca. 100MB
ca. 500MB
ca. 65MB
ca. 50MB
ca. 20MB
ca. 10MB
ca. 40MB
ca. 20MB
ca. 1MB
ca. 5MB
ca. 300MB Always
installed
