Omron CX-ONE - INTRODUCTION GUIDE 1 Introduction Manual page 53

各種PLC
PLC Network
ネットワーク PLC
Start-Up
Start-Up
の立ち上げ
Check the temperature
controller that is not
displayed properly and
configure it correctly
Perform step (2) from two
pages ago
Right-click on the
communications Unit
number #002 icon in the
[Network Structure] window,
then select [Start Special
Application] > [Start with
Setting Inherited]
After parameter settings
are finished, select
[Communications] >
[Download to Device], then
select either [Download all],
[Download Changed
Parameters], or [Download
Changed from Default]
DeviceNet NT Link
Start-Up Start-Up
(5) Check the settings of the temperature controller that is not displayed in the [Network
Structure] window (baud rate, data length, stop bit, parity, Unit number), configure it correctly,
then re-upload (Perform step (2) from two pages ago). The [Network Structure] window is
updated.
(6) Move the cursor on E5CN of communications Unit number #002, then select [Start Special
Application] > [Start with Setting Inherited].
(6) Dedicated Support Software CX-Thermo is started with the same model and setting as
that of the temperature controller.
After parameter settings are finished, download the settings to the E5CN of
communications Unit number #002.
Controller
CompoWay
Link
/F Start-Up
Start-Up
Saving Equipment
System Disass'y /
Config. Reass'y
The [Network Structure] window
shows only the Units for which
connection is established, and Units
with incorrect communications
setting are not displayed.
Now the correctly configured Unit is
displayed and you can confirm that
communications settings are correct.
System Controller
Config. Link
Verification Diagnosis
