Online Debug on Reading
a Machine
Start NS transfer
Start NS transfer
program
program
Click on
Setup
Setup
communication route
communication route
Check "Pass thru PLC"
in the Comm. Method
window
Select Serial(Toolbus)
Select NT Link
Transfer screen data
Transfer screen data
Click OK to start transfer
Online
Connection
Project
to PLC
Transferring NS screen data
Transferring NS screen data
This section describes how to transfer screen data to the NS through PLC without changing
cables.
From [Start] menu, select [Programs] > [OMRON] > [CX-One] > [CX-Designer] > [CX-Designer
Ver.1.0] to start CX-Designer. (Or select [All Programs] > [OMRON] > [CX-One] > [CX-Designer]
> [CX-Designer Ver.1.0].) Open a project saved in the previous section.
Select [Transfer]-[Transfer[To PT...]] from the [PT] menu.
Setup "Data transfer to
the NS through PLC".
Transferring
Program
to a
Debug
Machine
Press each setting button.
*Communication between the NS and the PLC
must be established before transferring screen
data through PLC without changing cables.
If "Connecting..." is displayed at the right bottom
of the screen, use Auto Connection (See Chapter
3 1-3 "Setup NT Link") to connect the NS and the
PLC before starting the following procedure.
If the communication between the NS and the
PLC has already been established, you do not
need to perform the operation described above.
Check "Pass thru PLC" to activate
the "PC PLC
Select PC – PLC – NS.
Screen data transfer is
Screen data transfer is
complete at 100%.
complete at 100%.
NS" route setting.
Set the serial port
COM No. for PC
PLC connection.
Then, press OK.
Enter NS Unit No.
Then, press OK.
