Omron CX-ONE - INTRODUCTION GUIDE 1 Introduction Manual page 20

Starting CX-
Design
Programmer
Double-click NCF Unit
Select
[Communications Setting]
Click
Double-click the servo
driver
Save the project
Setting
Creating Unit
CPU Bus
Configuration
Units/SIOU
Edit NCF Unit parameters.
Double-click NCF Unit.
Edit servo parameters.
Set servo parameters for axis 01 as shown below.
Pn50A(input signal selection 1): 2881
Pn50B(input signal selection 2): 8883
Pn511(input signal selection 5): 6541
Refer to Page 2-13 "Saving Project" for details.
Checking I/O
Programming
Assignment
Set axis parameters
for axis 01.
Click
Saving
Offline Debug
a Project
Set output relay area to
CIO100 and input relay
area to CIO500.
Select [Axis 01].
Click
