5.1.5.3 NORMAL OPERATING POSITION
45°
WARNING
©Copyright Task Force Tips LLC 2002-2024
Slow Closer
Operating Range
Horizontal
45°
Quickly releasing the trigger outside normal operating orientation will likely cause faster valve shut
off, increasing risk of a burst hose. This could result in injury. Slowly release the trigger when
operating outside of the nozzle's normal orientation.
Figure 5.1.5.3
12
90°
Slow Closer
Operating Range
15°
LIN-035 May 20, 2024 Rev17
