Device layout
Active key
Volume key
Side key
Speaker
Home key
(Fingerprint
recognition
sensor)
Recents
key
Keyboard
dock port
Main antenna
(SM-T636B)
Speaker
Rear camera
Back cover
9
EN
Front camera
Microphone
Light sensor
Microphone
Multipurpose
jack
(USB Type-C)
Earphone jack
Touchscreen
Back key
GPS antenna
Flash
NFC antenna
