Operation, Parts
DutyMax EH/GH
Hydraulic Sprayers
For professional use only.
Not approved for use in explosive atmosphere or hazardous locations.
For portable airless spraying of architectural paints and coatings.
3300 psi (22.8 MPa, 228 bar) Maximum Working Pressure
See page 3 for model information, including maximum working pressure and approvals.
Important Safety Instructions
Read all warnings and instructions in this manual and in related manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
308491
DutyMax DH/GH230 Gun
309495
DutyMax GH300 Gun
Standard Series
Use only genuine Graco replacement parts.
The use of non-Graco replacement parts may void warranty.
230/300, DH230 HD
Related Manuals:
334654
310812
ti25305a
Pump
Electric Motor
ProContractor Series
334606J
EN
ti25306a

Advertisement

loading
Need help?

Need help?

Do you have a question about the 308491 and is the answer not in the manual?

Questions and answers

Summary of Contents for Graco 308491

  • Page 1 Be familiar with the controls and the proper usage of the equipment. Save these instructions. Related Manuals: 308491 DutyMax DH/GH230 Gun 334654 Pump 309495 DutyMax GH300 Gun 310812 Electric Motor ti25306a ti25305a Standard Series ProContractor Series Use only genuine Graco replacement parts. The use of non-Graco replacement parts may void warranty.
  • Page 2 Graco Standard Warranty ........
  • Page 3: Troubleshooting

    Hydraulic fluid too low Shut off sprayer. Add fluid*. See page 16 Belt worn or broken or off Replace. Hydraulic pump worn or Bring sprayer to Graco damaged distributor for repair Dried paint seized paint pump Service pump. See manual 334654 Hydraulic motor not shifting Set pump valve OFF.
  • Page 4 Power switch is not ON Turn power switch ON Tripped circuit breaker Check circuit breaker at power source. Reset motor switch *Check hydraulic fluid level often. Do no allow it to become too low. Use only Graco hydraulic fluid, page 16. 334606J...
  • Page 5: Graco Standard Warranty

    Graco’s written recommendations. This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts.
  • Page 6: Graco Information

    For the latest information about Graco products, visit www.graco.com. For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call 1-800-690-2894 to identify the nearest distributor. All written and visual data contained in this document reflects the latest product information available at the time of publication.
