Operation, Parts
DutyMax EH/GH
Hydraulic Sprayers
For professional use only.
Not approved for use in explosive atmosphere or hazardous locations.
For portable airless spraying of architectural paints and coatings.
3300 psi (22.8 MPa, 228 bar) Maximum Working Pressure
See page 3 for model information, including maximum working pressure and approvals.
Important Safety Instructions
Read all warnings and instructions in this manual and in related manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
308491
DutyMax DH/GH230 Gun
309495
DutyMax GH300 Gun
Standard Series
Use only genuine Graco replacement parts.
The use of non-Graco replacement parts may void warranty.
230/300, DH230 HD
™
Related Manuals:
334654
310812
ti25305a
Pump
Electric Motor
ProContractor Series
334606J
EN
ti25306a
Advertisement
Related Manuals for Graco 309495
Summary of Contents for Graco 309495
- Page 1 Be familiar with the controls and the proper usage of the equipment. Save these instructions. Related Manuals: 308491 DutyMax DH/GH230 Gun 334654 Pump 309495 DutyMax GH300 Gun 310812 Electric Motor ti25306a ti25305a Standard Series ProContractor Series Use only genuine Graco replacement parts. The use of non-Graco replacement parts may void warranty.
- Page 2 Graco Standard Warranty ........
-
Page 3: Technical Data
Technical Data Technical Data DutyMax EH230 HD Standard Series Metric Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar Hydraulic reservoir capacity 1.25 gallons 4.75 liters Motor 2.2 kW 3.0 HP Voltage, Amperage Frequency Phase 220 VAC, 15.0 A 220 VAC, 15.0 A, 50 Hz, 1 phase 50 Hz, 1 phase... - Page 4 Technical Data DutyMax EH300 HD Standard Series Metric Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar Hydraulic reservoir capacity 1.25 gallons 4.75 liters Motor 5.5 kW 7.5 HP Voltage, Amperage Frequency Phase 400 VAC, 11.0 A 400 VAC, 11.0 A, 50 Hz, 3 phase 50 Hz, 3 phase Maximum tip size...
- Page 5 Technical Data DutyMax GH230 HD Standard Series Metric Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar Hydraulic reservoir capacity 1.25 gallons 4.75 liters Maximum hydraulic pressure 1855 psi 12.8 MPa,128 bar Engine 200 cc (6.5 HP) Maximum tip size 0.053 Maximum free-flow delivery 2.35 gpm...
- Page 6 Technical Data DutyMax GH300 HD Standard Series Metric Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar Hydraulic reservoir capacity 1.25 gallons 4.75 liters Maximum hydraulic pressure 1855 psi 12.8 MPa,128 bar Engine 270 cc / 305 cc (9.0 HP / 10.0 HP) Maximum tip size 0.057 Maximum free-flow delivery...
- Page 7 Technical Data DutyMax EH230 HD ProContractor Series Metric Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar Hydraulic reservoir capacity 1.25 gallons 4.75 liters Engine 2.2 kW 3.0 HP Voltage, Amperage Frequency Phase 220 VAC, 15.0 A 220 VAC, 15.0 A, 50 Hz, 1 phase 50 Hz, 1 phase Maximum tip size...
- Page 8 Technical Data DutyMax EH300 HD ProContractor Series Metric Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar Hydraulic reservoir capacity 1.25 gallons 4.75 liters Engine 5.5 kW 7.5 HP Voltage, Amperage Frequency Phase 400 VAC, 11.0 A 400 VAC, 11.0 A, 50 Hz, 3 phase 50 Hz, 3 phase Maximum tip size...
- Page 9 Technical Data DutyMax DH230/GH230 HD ProContractor Series Metric Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar Hydraulic reservoir capacity 1.25 gallons 4.75 liters Maximum hydraulic pressure 1855 psi 12.8 MPa,128 bar Engine DH230 350 cc (6.7 HP) GH230 200 cc (6.5 HP) Maximum tip size 0.053...
- Page 10 Technical Data DutyMax GH300 HD ProContractor Series Metric Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar Hydraulic reservoir capacity 1.25 gallons 4.75 liters Maximum hydraulic pressure 1855 psi 12.8 MPa,128 bar Engine 270 cc / 305 cc(9.0 HP / 10.0 HP) Maximum tip size 0.057 Maximum free-flow delivery...
- Page 11 Technical Data GH230/300 OEM 24W299 Hydraulic Return, Hydraulic 37º flare, Inlet, 37º flare, 1.813 in. 3/4-16 UNF-2A 3/4-16 UNF-2A (46.05 mm) 2.25 in. (57.15 mm) 2.25 in. (57.15 mm) 1.813 in. (46.05 mm) 1.813 in. 3/4 - 14 (46.05 mm) NPT Male Mounting Screw (4), Socket Cap Screw 1in.
- Page 12 Technical Data Notes 334606J...
- Page 13 Technical Data Notes 334606J...
-
Page 14: Graco Standard Warranty
Graco’s written recommendations. This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts. -
Page 15: Graco Information
For the latest information about Graco products, visit www.graco.com. For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call 1-800-690-2894 to identify the nearest distributor. All written and visual data contained in this document reflects the latest product information available at the time of publication.
