- Page 1 Operator’s Manual Spray Star 1200 Truck Model 20-500-D Manual System 1201 TeeJet Radion 8140 1202 ® TeeJet 744 1204 ® TeeJet Aeros/DynaJet 1215/1218/1220 ® TeeJet Radion/DynaJet 1207/1208 ® SN: 12246 Product Support: Hwy SS & Poplar Ave; Cameron WI 54822 1-800-891-9435 productsupport@smithco.com...
-
Page 2: Table Of Contents
CONTENTS Introduction ..............1-8 Introduction ..............1 Symbols ..............2 General Safe Practices ..........3-6 Specifications ............. 7 Optional Spray Equipment .......... 7 Set Up ................. 8 Operation ..............9-14 Controls & Instruments ........... 9-10 Operating Instructions ...........11-12 Tank Agitation ............13 Spray Cleaning ............ -
Page 3: Introduction
All Smithco machines have a Serial Number and Model Number. Both numbers are needed when ordering parts. The serial number plate on the Spray Star 1200 is located on the left main frame, by front bumper. Re- fer to engine manual for placement of engine serial number. -
Page 4: Symbols
Hand Throttle Oil Level Park Brake Park Brake Slow Fast Lift Arm Release Hydraulic Fluid Hot Surface No Riders Moving Parts Pinch Point Penetration 20° MAX Rollover Warning Blower Headlamp Seat Belt Danger Danger Caution PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 5: General Safe Practices
It may also be used to alert against unsafe practices. IMPORTANT: Blue. Indicates procedures which should be followed to avoid damage to the machine. PARTS MANUALS AVAILABLE ONLINE AT smithco.com... - Page 6 Decal, Gas J* 25-286 Decal, Pinch Point K 25-356 Decal, Tire Pressure L 25-373 Decal, Smithco M 25-381 Decal, 96 dBA N 27-077 Decal, Smithco O** 27-093 Decal, Hydraulic Oil P** 25-277 Decal, Battery PARTS MANUALS AVAILABLE ONLINE AT smithco.com...
- Page 7 18. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase. 19. Use parts and materials supplied by Smithco only. Do not modify any function or part. 20. Use caution when booms are down as they extend out beyond the center line of the machine.
- Page 8 If using Simulated Speed with a Radion 8140, one needs to change back to Ground Speed for proper rate control when spraying. PARTS MANUALS AVAILABLE ONLINE AT smithco.com...
-
Page 9: Specifications
15-968 26 Gal. Wash System with Electric Pump 17-601 15' HD Boom 17-585 18' HD Boom 17-580 20' HD Boom 15-967 Hose Reel Mount Kit 16-129 Manual Rewind Hose Reel, 200-foot/61-meter capacity 16-906 Electric Rewind Hose Reel, 200-foot/61-meter capacity PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 10: Setup
SETUP The Spray Star 1200 arrives from Smithco setup and ready for service. Depending on freight conditions the battery may have to be installed. The spray system is normally shipped attached to the 1200 Prime Mover. If a spray system is to be fitted to a Prime Mover by a dealer or factory, assemble and attach the components in accordance with the parts draw- ings in the Spray Star 1200 Parts/Service Manual. -
Page 11: Operation
0 mph. Pointer will stay at 0 mph and oscillate slightly at zero to indicate the GPS is acquiring satellites. GPS is not yet functional to indicate speed. Once satellites are acquired (15-45 seconds), the pointer will swing full scale and then back toward 0 mph to indicate it is now ready for operation. PARTS MANUALS AVAILABLE ONLINE AT smithco.com... - Page 12 2. Obtain desired speed with foot pedal. 3. Step on foot switch(T) to lock speed. 4. Push foot switch again to disengage. To avoid abrupt stop, place foot on traction pedal before disengaging speed control. PARTS MANUALS AVAILABLE ONLINE AT smithco.com...
-
Page 13: Operating Instructions
3. Remove the ignition key and engage the park brake. Never leave the vehicle unattended with the engine running. Always bring the vehicle to a complete stop, engage park brake, turn key off and remove key. PARTS MANUALS AVAILABLE ONLINE AT smithco.com... - Page 14 4. Connect other end of cable (D) to engine block on unit being started (NOT to negative (-) terminal of battery) To prevent damage to other electrical components on unit being started, make certain that engine is at idle speed before disconnect- ing jumper cables. PARTS MANUALS AVAILABLE ONLINE AT smithco.com...
-
Page 15: Tank Agitation
Hold one in place and turn the other wrench to loosen assembly. Once apart, clean with water and check for deteriorating parts. Replace parts as needed by ordering the Spare Parts Kit 20-673-01P. PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 16: Spray Cleaning
Located to the right of the control panel. Use lever on compressor to designate which boom is to be used to dis- pense foam. Use dial located on the foamer to adjust pressure for the amount of foam that will be dispensed. Switch on compressor also turns foamer on or off. PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 17: Diagrams
WIRING DIAGRAM Color Code Chart Blue Brown Yellow Green Orange Black Gray White PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 18: Hydraulic
HYDRAULIC DIAGRAM PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 19: Reference
Widna tal-Operatur ▪ Dopuszczalny poziom hałasu dla operatora ▪ Nível sonoro nos ouvidos do operador ▪ Nivelul zgomotului la urechea operatorului ▪ Hladina hluku pôsobiaca na sluch operátora ▪ Raven hrupa pri ušesu upravljavca ▪ Nivel sonoro en el oído del operador ▪ Ljudnivå vid förarens öra PARTS MANUALS AVAILABLE ONLINE AT smithco.com... - Page 20 Hyväksyntänumero ▪ Numéro de certificat ▪ Bescheinigungsnummer ▪ Αριθμός Πιστοποιητικού ▪ Hitelesítési szám ▪ Numero del certificato ▪ 205002023-2 Sertifikāta numurs ▪ Sertifikato numeris ▪ Numru taċ-Ċertifikat ▪ Numer certyfikatu ▪ Número do Certificado ▪ Număr certificat ▪ Číslo osvedčenia ▪ Številka certifikata ▪ Número de certificado ▪ Certifikatsnummer PARTS MANUALS AVAILABLE ONLINE AT smithco.com...
-
Page 21: Quick Reference
Hydraulic Fluid SAE 10W-40 API Service SJ or higher Motor Oil OTHER PARTS 16-953 Hinged Cover On Tank with Gasket 16-953-01 Gasket For Cover 16-169 Strainer Basket 15-818 #75 Fitting Oring 15-817 #50 Fitting Oring Spark Plugs Champion type RC12YC (Gap 0.040 inch (1.02mm)) PARTS MANUALS AVAILABLE ONLINE AT smithco.com... - Page 22 30 days from discovery of the condition. If you need help locating an Authorized Smithco Distributor, or if you have questions regarding your warranty rights or responsibilities, you may contact us at: Smithco Product Support Department 200 West Poplar Ave.
- Page 23 This warranty does not apply to normal “wear and tear” items. Normal “Wear and Tear” includes, but is not limited to, damage to seats due to wear or abrasion, worn painted surfaces, scratched decals or windows, etc. Smithco may require the return of failed parts or components in order to determine the validity of any warranty claim.
