Operating Instructions • Warning Information
ALWAYS READ INSTRUCTIONS BEFORE
USING POWER TOOLS
ALWAYS WEAR SAFETY GOGGLES
ALWAYS WEAR HEARING PROTECTION
AVOID PROLONGED EXPOSURE TO VIBRATION
SPECIFICATIONS
Free Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . 190 RPM
Maximum Torque . . . . . . . . . . . . . . . . . . . . . . . 90 ft. lbs.
Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . . 4 CFM
Air Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4" NPT
Recommended Hose Size . . . . . . . . . . . . . . . . . .3/8" I.D.
Recommended Air Pressure . . . . . . . . . . . . . . . . 90 psig
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10.83"
Net Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.82 lbs.
Sound Pressure Level. . . . . . . . . . . . . . . . . . . . . .99 dbA
CAT5500HD
• Parts Breakdown
WARNING
Some dust created by power sanding, sawing,
grinding, drilling, and other construction activities
contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples
of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending
on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well
ventilated area, and work with approved safety
equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
CAT5500HD
3/8" Air Ratchet
Copyright © Professional Tool Products, 2015
All rights reserved
1/29/15
