3.1.3 System Error – Contact Your
Physician
If a system error occurs, your device will beep for 5 sec-
onds twice and will show the red LED light. This will hap-
pen within the first minute of the system error occurring.
After that, the device will blink the red LED light for one
second every minute (see Figure 5).
■ Note:
A system error means that treatment is stopped. Please
contact your physician as soon as possible.

3.1.4 Emergency Stop Button

The System emergency stop button is located on the side
of the control box (see Figure 6). It is a switch that will
disable the motors from moving. The button is there to
enable you, as the patient, to stop the device in case of
emergency. Your physician can help you to understand
what types of situations would be considered an emer-
gency. If pressed during active treatment, the motors will
stop moving immediately. The System will beep for 5 sec-
onds twice and will display the red and orange LED lights.
After that, the red and orange lights will blink for one sec-
ond every minute as shown in Figure 7. If pressed while
the device is not in active treatment, nothing will happen
until it is time for the next active treatment to occur.
When this time comes, the device will sense that the
emergency stop button has been pressed and will not
start treatment. Instead, it will display the emergency stop
sounds and lights as described already in Figure 7.
■ Note:
Treatment is stopped until system is reactivated by the
physician. Please contact your physician as soon as possi-
ble for any situation in which the emergency stop button
was pressed. You will not be able to restart the device
yourself and you will be required to go to your physician's
clinic for reactivation.
Figure 5: System error
Figure 6: Emergency stop button
Figure 7: Emergency stop button
