Samcon RoughCam miniTube IP User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
RoughCam
miniTube IP
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RoughCam miniTube IP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samcon RoughCam miniTube IP

Summary of Contents for Samcon RoughCam miniTube IP

  • Page 1 ® RoughCam miniTube IP User Manual...

  • Page 2: Table Of Contents

    Table of contents Introduction ......................4 Technical data ......................4 Illustration of the model key ................. 4 Electrical parameters of the camera ..............5 Connection cable....................5 Video-technical characteristics ................6 Other technical data .................... 6 Safety Instructions ....................7 Installation ........................
  • Page 3 Figure 2-2 Sectional view of ASKD02-T ................6 Table 2-2 Other technical data ..................6 Table 4-1 Mounting accessories ..................8 Figure 5-1 RoughCam miniTube IP Potential equalization ..........9 Table 5-1 Potential equalization ..................9 Figure 5-2 System-Cable gland and cable............... 10 Figure 5-3 RoughCam miniTube IP T10-VA1.2.K1.BOR-N.N-xxx.x-T ......

  • Page 4: Introduction

    1/2.8“ CMOS sensor for great image quality and incomparable light sensitivity. To see other approvals, please visit our website at www.samcon.eu/en When designing the RoughCam miniTube IP, we attached a very high importance to safety, mechanical precision and high quality of stainless steel. Technical data...

  • Page 5: Electrical Parameters Of The Camera

    Bending radius: 20 x D when installed and 10 x D after relocation Data line: 4 x 2 x AWG23/1 CAT.6 Properties: PUR halogen-free, flame-retardant, UV-re- sistant, chemical resistance, shielded (see www.samcon.eu Quicklink: https://www.samcon.eu/fileadmin/documents/en/60- Assembling%26mounting/ASKD02-T_Datasheet.pdf Doc.-ID: 240507-PT10BA-HS-RoughCam-miniTube-IP_en_rev.00.docx, Page 5 of 24...

  • Page 6: Video-Technical Characteristics

    Figure 2-2 Sectional view of ASKD02-T Video-technical characteristics We use the eneo Module Network Camera in a pressure-resistant enclosure. For details, ® please refer to the Product Documentation, video-technical data of eneo https://eneo-security.com/en/ism-72m2713w0a.html Other technical data Camera Terminal box -30°C … +50°C -60°C …...

  • Page 7: Safety Instructions

    Safety Instructions It is absolutely mandatory to adhere to the national safety regulations and regula- tions for prevention of accidents, as well as to the safety instructions given below in this User Manual! Attention! Repairs may only be carried out by using original parts from the manu- facturer.
  • Page 8 Install the terminal box so that a good ac- cessibility is provided, in order to facilitate electrical connection. Drawings for drill hole patterns and further information can be viewed on our product page: Quick link: https://www.samcon.eu/en/products/roughcam/roughcam-minitube-ip/ Optional mounting accessories WALL MOUNT WMB-VA0.x/1.x Wall bracket Wall bracket for cameras of the T10-VA1.x-Series...

  • Page 9: Electrical Connection

    The user is NOT authorised to do electrical connection procedures inside the enclosure. Potential equalization Figure 5-1 RoughCam miniTube IP Potential equalization Potential equalization/grounding of the camera housing is absolutely necessary, in order to avoid static charges and thus the formation of sparks. For this purpose, a screw terminal is provided at the rear side, at the bottom (right) (see Figure 5-1).

  • Page 10: Connection Work At The Device (Terminal Box) And Fuses

    The figures 5.3 and 5.4 illustrate the potential cable terminations of the RoughCam miniTube IP. Possible terminations are: terminal box or plug. Figure 5-3 RoughCam miniTube IP T10-VA1.2.K1.BOR-N.N-xxx.x-T Figure 5-4 RoughCam miniTube IP T10-VA1.2.K1.BOR-N.N-xxx.x-P Doc.-ID: 240507-PT10BA-HS-RoughCam-miniTube-IP_en_rev.00.docx, Page 10 of 24...
  • Page 11 Video Tutorial: Observe our video tutorial: “SAMCON 01 Wiring the cable SKDP03-T to the junction box ExTB-3” https://go.samcon.eu/v01 Figure 5-5 Video Tutorial ExTB-3 The pin assignment of the SKD01-T is executed in accordance with the standard EIA/TIA- 568B as follows:...
  • Page 12 SKD02-T SKD02-T RoughCam miniTube housing Figure 5-6 Sample circuit of terminal box PD/ RoughCam miniTube IP Figure 5.7 – Connection to the terminal box Doc.-ID: 240507-PT10BA-HS-RoughCam-miniTube-IP_en_rev.00.docx, Page 12 of 24...

  • Page 13: Fusing

    5.2.2 Plug assignments (RJ45) The data transfer of the RoughCam miniTube IP uses a 100 Mbit/s Ethernet connection (100BASE-TX). If the cable termination uses a plug, the latter should be plugged into the RJ45 PoE slot of the network device (PSE).

  • Page 14: Tests Prior To Switching On Voltage

    Detailed instructions on how to connect a RJ45 plug are available in our video tutorial: “SAMCON 03 Mounting and installing the RJ45 jack to SAMCON cables” https://go.samcon.eu/v03 Figure 5-12 Plug assignment, RJ45 5.2.3 Tests prior to switching on voltage Attention! Prior to starting the device, perform all tests as indicated by the national regulations.

  • Page 15: Working Inside The Camera Housing

    Opening the pressure-resistant housing If the RoughCam miniTube IP is equipped with a weather protection roof this has to be removed prior to starting your work! To do so, loosen the 4x12mm button head screws M4*0.7 at the front and rear sides of the bracket holders (Figure 6-1).
  • Page 16 Figure 6-2 Opening RoughCam miniTube IP Carefully pull out the cable and supply flange to the rear, as straight as possible. Because of negative pressure, it may be difficult to remove the flange. Attention: The mounting adapter with the camera module and optics, as well as the tem- perature control, and (if applicable) auxiliary relays and terminal block are fixed on the cable and supply flange.

  • Page 17: Hardware Reset

    Hardware Reset To set all the parameters of the RoughCam miniTube IP (including the IP address) to de- fault values, you should run a hardware reset. The parameters can be reset via the web interface or manually. If the camera placed in the network can no longer be reached or its state is uncontrollable, the reset should be per- formed manually.
  • Page 18 Attention! Do not lock-in any foreign objects in the housing. Dismantled screw locks (spring washers DIN 127A) must be used again. The GYLON® gasket must be used in undamaged condition, according to the flange hole pattern, and placed between the flange and the hull. The lateral position of the flat surface / contact surface is arbitrary.

  • Page 19: Network Access And Visualization

    Network access and visualization The camera is configured via the device's own website, the video stream can be accessed via RTSP or you can integrate the camera into your video management system using the ONVIF protocol. Network access The camera obtains an IP address via DHCP. If there is no DHCP server on the network, the default IP address is 192.168.1.10 Default username: admin Default password: admin...

  • Page 20: Web Interface, Configuration And Control

    234669_en_short_man.pdf (eneo-security.com) 234669_en_man.pdf (eneo-security.com) When delivered the RoughCam miniTube IP is set to the applicable network frequency. PAL = 50Hz (Europe) / NTSC = 60Hz (USA) Doc.-ID: 240507-PT10BA-HS-RoughCam-miniTube-IP_en_rev.00.docx, Page 20 of 24...

  • Page 21: Visualization, Rtsp Video Stream

    Visualization, RTSP video stream The camera's video stream can be visualized via the following addresses: RTSP rtsp://<user>:<password>@<ip>:554/1/stream1 rtsp://<user>:<password>@<ip>:554/1/stream2 rtsp://<user>:<password>@<ip>:554/1/stream3 Example: rtsp://admin:admin@192.168.1.10:554/1/stream1 JPG (Stream 3) http://<ip>/cgi-bin/snapshot.jpg MJPG (Stream 3) http://<ip>/cgi-bin/jpegpush.cgi ONFIV, VMS-Integration The camera can be integrated into your video management system (VMS) via ONVIF Pro- file S and Profile T.

  • Page 22: Maintenance / Modification

    Repairs may only be carried out with original parts of SAMCON Prozessleittechnik GmbH. In case of doubt, send the part in question back to SAMCON Prozessleittechnik GmbH. Reparations must only be carried out in accordance with nationally applied regulations by SAMCON Prozessleittechnik GmbH or by an authorised electrical technician authorised by SAMCON Prozessleittechnik GmbH.
  • Page 23 If you wish additional technical information, please contact us at: support@samcon.eu Doc.-ID: 240507-PT10BA-HS-RoughCam-miniTube-IP_en_rev.00.docx, Page 23 of 24...
  • Page 24 Schillerstrasse 17, 35102 Lohra-Altenvers, Germany www.samcon.eu, info@samcon.eu Phone: +49 6426 9231-0, fax: - 31...
