  • Page 1 ® ExCam XI80 User Manual...

  • Page 2: Table Of Contents

    Table of contents Introduction ......................4 Technical data ......................4 Explosion protection .................... 4 Illustration of the model key ................. 5 Electrical parameters of the camera ..............6 System cable SKDP03-T ..................6 Optical specifications ................... 6 Video-technical characteristics ................8 Other technical data ....................
  • Page 3 Table 2-2 Measurement field and pixel size ..............7 Table 2-3 Other technical data ..................8 Table 4-1 Mounting accessories ..................12 Figure 5-1 ExCam XI80 Potential equalization ..............13 Table 5-1 Potential equalization ..................13 Figure 5-2 ExCam XI80 T08-VA0.4.K1.GER-N.N-xxx.N-P ..........14 Figure 5-3 ExCam XI80 T08-VA0.4.K1.GER-N.N-xxx.N-T ..........

  • Page 4: Introduction

    (e.g. thermal analysis with hot and cold spots). The ExCam XI80 cannot only see where it is hot, it can also measure the temperature exactly; and all that in an 8 millisecond interval (Real Time Recording).

  • Page 5: Illustration Of The Model Key

    N.N- 005.N- 012/030/0 55/080 Table 2-1 Model key Explanations: ExCam XI80 = Functional camera description of the ExCam Series (technical data/ specification of the individual camera module) T08 = SAMCON Production- Type 08 VA0.4.K1.GER = T07 ex d housing (stainless steel 1.4404) with small diameter Ø...

  • Page 6: Electrical Parameters Of The Camera

    Please note that the ExCam XI80 has a fixed optic. A change of optics is not possible. The following table shows a relationship between the measurement object distance and the pixel size on the object level.
  • Page 7 55°-optic Distance to measurement object [m] 0,05 Enlargement of HFOV 0,057 0,11 0,218 0,325 0,539 1,07 2,14 4,27 6,41 10,7 106,7 total measuring VFOV 0,057 0,11 0,218 0,325 0,539 1,07 2,14 4,27 6,41 10,7 106,7 field at object level [m] DFOV 0,08 0,156...

  • Page 8: Video-Technical Characteristics

    Video-technical characteristics We use the Optris Xi80 Spot-finder IR-Camera in a pressure-resistant enclosure. For de- ® tails, please refer to the Product Documentation, video-technical data of optris https://www.optris.com/optris-xi-80 Other technical data Camera Terminal box -10°C … +50°C -60°C … +55°C Permissible ambient temperature Protection class as per EN IP66/68...

  • Page 9: Safety Instructions

    Please absolutely observe the installation instruction’s safety directions of the T08 ExCam series! Quick link: https://www.samcon.eu/fileadmin/documents/en/22-Ex-Network-Cameras/ExCam-Series-T08-EX-Installation-Manual-2020.pdf It is absolutely mandatory to adhere to the national safety regulations and regula- tions for prevention of accidents, as well as to the safety instructions given below...
  • Page 10 Attention! Adhere to the warnings given on the nameplate: “WARNING – DO NOT OPEN IN HAZARD AREAS“ Using the camera in explosion-protected areas with regard to tempera- ture and dust layers is defined in the respective national regulations. When installing the ExCam, adhere to the requirements of the EN/IEC 60079-14.

  • Page 11: Installation

    Installation For commissioning and operating the camera, the relevant national regulations, as well as the generally accepted rules of technology shall prevail. Before mounting the camera, thoroughly check it for any transport damage regarding the housing and cable. Installa- tion, electrical connection and the first commissioning must only be carried out by quali- fied specialists.
  • Page 12 Drawings for drill hole patterns and further information can be viewed on our product page: Quick link: https://www.samcon.eu/en/products/network/excam-xi80/ Optional mounting accessories WALL MOUNT BRACKET WMB-VA0.x/VA1.x Wall bracket Wall bracket for devices of T08-VA0-series WMB-... Suitable for hanging the camera on walls.

  • Page 13: Electrical Connection

    (T08). Potential equalization Figure 5-1 ExCam XI80 Potential equalization Potential equalization/grounding of the camera housing is absolutely necessary, in order to avoid static charges and thus the formation of sparks. For this purpose, a screw termi- nal is provided at the rear side’s bottom (see Figure 5-1).

  • Page 14: Variants Of Cable Termination

    Variants of cable termination Figures 5.2 and 5.3 illustrate the cable termination of the ExCam XI80. Figure 5-2 ExCam XI80 T08-VA0.4.K1.GER-N.N-xxx.N-P Figure 5-3 ExCam XI80 T08-VA0.4.K1.GER-N.N-xxx.N-T Connection work at the device (terminal box) Attention! Never open the Ex-e terminal box under voltage!
  • Page 15 Figure 5-4 Video Tutorial ExTB-3 The pin assignment of the SKDP03-T is executed in accordance with the standard EIA/TIA-568B for 24VDC, as follows: Figure 5-5 Pin assignment of the cable SKDP03-T Camera (Ex-d) Colour Terminal Cross- Comment SKDP03-T ExTB-3 sectional (T568B) (IEC60757) surface...
  • Page 16 Figure 5-6 Wired terminal box ExTB-3 Particularly in EMC critical environments, it is necessary to make sure that the cable shield is grounded on side of the terminal block! The maximum cable length is 100 m. Attention! Finally, check your network installation. Attention! Cables and wires must comply with the requirements of the IEC 60079-0/1/7 &...

  • Page 17: Plug-Assignment (Rj45)

    Example: Direct routing from ExTB-3 to safe area (24 VDC/IO) Figure 5-7 ExTB-3 -> Safe area Plug-assignment (RJ45) Figure 5-8 Plug assignment RJ45 If the cable termination uses a plug, the latter should be plugged into the RJ45 PoE slot of the network device (PSE).
  • Page 18 It is imperative to ensure a correct routing of the individual wires ac- cording to the EIA/TIA-568B" Detailed instructions on how to connect an RJ45 plug are available in our video tutorial: “SAMCON 03 Mounting and installing the RJ45 jack to SAMCON cables” https://go.samcon.eu/v03 Figure 5-9 Plug assignment, RJ45...

  • Page 19: Appropriate Cables & Cable Entries

    5.4.1 Appropriate cables & cable entries An integral part of the device safety is the correct selection of the cables, wires and cable entries. Attention! Cables and wires must comply with the requirements of the IEC 60079- 0/1/7 & 14. Attention! The supply line must have a sufficient cross-section.

  • Page 20: Network Access And Visualization

    Start \ Programs \ Optris GmbH \ PIX Connect 3. Select the desired language in the menu Tools → Language Allocating IP adress The ExCam XI80 is designed for use in an Ethernet network and requires an IP address for access and control. Software configurations...
  • Page 21 To do this, go to All Control Panel Items and open the Network and Sharing Center. Go to Ethernet. Now press Properties. Now select Internet Protocol Version 4 (TCP / IPv4) in the properties window and then go to Properties again. In the register card General, activate the check box “Use the following IP address”.
  • Page 22 Start the PIX Connect software and activate the Ethernet func- tion. To do this, go to Devices and Enable Ethernet in the menu. Make sure that all three networks (Domain, Private, Public) are allowed in the Windows Firewall win- dow to ensure a connection to the device Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 22 of 28...
  • Page 23 With the option “port no. assign automatically” a port number is assigned automatically. If several cameras with different port numbers are connected and communication is to take place with a specific camera, the corresponding camera can be determined by reacting to port number. The authorizations of programs can also be activated retrospectively in the Windows firewall settings of the PC (Windows firewall and allow a program or feature through Windows Firewall).

  • Page 24: Visualization/ Analysis Software Pix Connect

    Visualization/ Analysis Software PIX Connect General information about PIX Connect The configuration menu of the web surface allows an intuitive navigation and offers sev- eral configuration possibilities. For detailed documentation and information how to use the web interface, please see the Optris PIX Connect Operator’s Manual or visit the fol- lowing website: https://www.optris.com/optris-xi-80 The radiometric processing of the image data enables subsequent detailed image analy-...

  • Page 25: User Interface

    User interface There are many possibilities within the user interface. Figure 7-3 User interface 1. IR-Live view from the camera 2. Temperature profile: Temperature distribution on a maximum of two lines, which can be positioned anywhere in the image in terms of size and position. 3.

  • Page 26: Cleaning

    (e.g., proper condition of the casing, seals and cable entry points). If maintenance measures are necessary they have to be initiated and/or executed. Repairs may only be carried out with original parts of SAMCON Prozessleittechnik GmbH. Damaged pressure-resistant housings have to be replaced completely. In case of doubt, send the part in question back to SAMCON Prozessleittechnik GmbH.

  • Page 27: Drawings & 3D Models

    Drawings & 3D models All drawings, 3D models, certificates and other information are available in the download area of the product page on our website: https://www.samcon.eu/en/products/network/excam-xi80/ If you wish additional technical information, please contact us at: support@samcon.eu Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 27 of 28...
  • Page 28 Schillerstrasse 17, 35102 Lohra-Altenvers, Germany www.samcon.eu, info@samcon.eu Phone: +49 6426 9231-0, fax: - 31...
