- Page 1 niteZoom ® RoughCam User manual...
-
Page 2: Table Of Contents
Content Technical Data ......................4 Electrical parameters ................... 4 System cable SKAxx ................... 4 Mechanical parameters ..................4 Temperature range ....................5 Sensor ......................... 5 Lens ........................5 Electronical functions ..................5 Safety guidelines ...................... 6 Illustration of the model key ..................6 Commissioning ...................... - Page 3 Figure 4.5 RoughCam niteZoom – T10-VA-B-XXX-P-L ............. 9 Figure 4.6 Setting the Baud-transmission rate..............12 Figure 4.7 FCB Control Panel of the RoughCam niteZoom ..........13 Figure 4.8 Control and visualization via a video server ........... 13 niteZoom – lens and sensor board ..........14 ®...
-
Page 4: Technical Data
Technical Data Electrical parameters Camera: Supply voltage: +12 V DC to +30 V DC Reference power: +24 V DC Power input: 270 mA to 540 mA Maximum power input: 6.5 W (without heating) Heating (optional): Supply voltage: +12 V DC to +24 V DC Reference power: +24 V DC Power input:... -
Page 5: Temperature Range
Dimensions T10-VA [WxHxD]: , without pin and cable gland: 79 x 79 x 128 [mm] flange , with pin and cable gland: 79 x 96 x 128 [mm] flange , without pin and cable gland: 79 x 79 x 141 [mm] flange , with pin and cable gland: 79 x 96 x 141 [mm]... -
Page 6: Safety Guidelines
The following model options are currently available for the RoughCam niteZoom: Product name Model option Type housing Meter Cable Housing option SKA02 termin. heating 005- RoughCam niteZoom T10- T10- 005- T10- 005- T10- 005- T10- 005- T10- 005- T10- 005-... -
Page 7: Commissioning
Commissioning Attention! Please observe the national regulations regarding security, installa- tion, and accident prevention! Step 1: Installation ® Install the RoughCam niteZoom at the desired location. Warning! When the iris is open, the camera must not be directed toward the sun as this can cause damages to the sensor. -
Page 8: Potential Equalization
(fix) 4.2.2 Termination of the connection cable (pigtail) ® Corresponding to the selected model key, the RoughCam niteZoom can be delivered with the following cable termination options: Figure 4.2 RoughCam niteZoom – T10-VA-B-XXX-K-N Doc.-ID: 180816-PT10BA-HH-RoughCam niteZoom_en_rev.00.docx, page 8 of 20... -
Page 9: Figure 4.3 Roughcam Nitezoom - T10-Va-B-Xxx-K-L
Figure 4.3 RoughCam niteZoom – T10-VA-B-XXX-K-L Figure 4.4 RoughCam niteZoom – T10-VA-B-XXX-P-N Figure 4.5 RoughCam niteZoom – T10-VA-B-XXX-P-L Doc.-ID: 180816-PT10BA-HH-RoughCam niteZoom_en_rev.00.docx, page 9 of 20... -
Page 10: Power Supply & Protection
4.2.3 Power supply & protection Power supply & protection of the camera’s power circuit 4.2.4 The power supply is to be carried out via the red (RD) as well as black (BK) strand. Connection table: Potential Color (IEC 60757) Potential level Profile Comments +12 V DC…+30 V DC... -
Page 11: Video Picture Connection (Cvbs)
The dimensioning of the equipment or the supply protection depends on: The selected power supply The cable length The national regulations The following safety recommendations may serve as a basis: Supplied power Length system cable Recommended protection Comments 24 VDC <... -
Page 12: Tests Prior To Switching On Voltage
4.2.7 Tests prior to switching on voltage Attention! Prior to commissioning, all tests as indicated by the national regula- tions have to be executed. In addition, it is mandatory that the proper functioning of the operating device in accordance with this user man- ual and all other applicable regulation has been executed. -
Page 13: Figure 4.7 Fcb Control Panel Of The Roughcam Nitezoom
Figure 4.7 FCB Control Panel of the RoughCam niteZoom Figure 4.8 Control and visualization via a video server Doc.-ID: 180816-PT10BA-HH-RoughCam niteZoom_en_rev.00.docx, page 13 of 20... -
Page 14: Figure 4.9 Roughcam
(auto functions are disabled). In case that the RoughCam niteZoom is supposed to resume certain settings after the reboot, it is possible to configure „PRESETS“ via the FCB Control Panel, the video server or the VISCA Control Board. -
Page 15: Work Preparation
4.3.1 Work preparation Attention! Please carry out any preoperational work carefully and in accordance with the applicable regulations. 4.3.2 Opening the housing Opening the housing is only necessary for maintenance or repair work. If it is opened, please make sure not to damage any sealings and tighten the screws correctly as other- wise the IP protection level IP67 might be voided. -
Page 16: Maintenance / Servicing
Maintenance / Servicing The national regulations concerning the maintenance and servicing of electrical devices are to be observed. The required maintenance intervals are specific to the individual devices. The operating company has to determine these intervals depending on the application parameters. Dur- ing maintenance, focus has to be put on checking parts concerning the ignition protection category such as the integrity of the housing, the sealings and the cable glands. -
Page 17: Drawings
Drawings Figure 7.1 T10-VA-K1 Figure 7.2 T10-VA-K2 Doc.-ID: 180816-PT10BA-HH-RoughCam niteZoom_en_rev.00.docx, page 17 of 20... -
Page 18: Notes
Notes Doc.-ID: 180816-PT10BA-HH-RoughCam niteZoom_en_rev.00.docx, page 18 of 20... - Page 19 Doc.-ID: 180816-PT10BA-HH-RoughCam niteZoom_en_rev.00.docx, page 19 of 20...
- Page 20 Schillerstrasse 17, 35102 Lohra-Altenvers www.samcon.eu, info@samcon.eu fon: +49 6426 9231-0, fax: - 31 Doc.-ID: 180816-PT10BA-HH-RoughCam niteZoom_en_rev.00.docx, page 20 of 20...
