  • Page 1 ® RoughCam IPQ1615 User Manual...

  • Page 2: Table Of Contents

    Table of contents Introduction ......................4 Technical data ......................5 Illustration of the model key ................. 5 Electrical parameters of the camera ..............6 Connection cable....................6 2.3.1 Connection cable for models without heater (SKD01-T/ASKD02-T) ......... 6 2.3.2 Connection cable for models with heater (SKDP03-T/ASKDP03-T) ......... 7 Video-technical characteristics ................
  • Page 3 Table of Figures and Charts Figure 1-1 RoughCam IPQ1615 with weathershield and junction box ....... 4 Table 2-1 Model key ......................5 Figure 2-1 Sectional view of SKD01-T ................6 Figure 2-2 Sectional view of ASKD02-T ................7 Figure 2-3 Sectional view of SKDP03-T ................7 Figure 2-4 Sectional view of ASKDP03-T ................

  • Page 4: Introduction

    PTFE sealings, not only the protection level IP68 is reached but also the chemical resistance is maximized. When designing the RoughCam IPQ1615 MKIII, we attached a very high importance to mechanical precision and high quality of stainless steel.

  • Page 5: Technical Data

    VA2.3.K3.BOR2- LL.H- 005.A- Table 2-1 Model key Explanations: RoughCam IPQ1615 = Functional camera description of the RoughCam Series (technical data/ specification of the individual camera module) T10 = SAMCON Production- Type 10 (for safe areas) VA2.3.K3.BOR2 = T11 housing (stainless steel 1.4404) with large diameter Ø...

  • Page 6: Electrical Parameters Of The Camera

    Electrical parameters of the camera Supply of 24 V DC for the heating: Voltage supply: 22 V DC < U < 26 V DC Power consumption: Approx. 40W@-60°C (depends on temperature) Power supply of the camera via Ethernet (PoE): Voltage supply: PoE, IEEE 802.3af/802.3at type 1 class 3 Reference voltage: +48 V DC (44...54 V DC)

  • Page 7: Connection Cable For Models With Heater (Skdp03-T/Askdp03-T)

    4 x 2 x AWG23/1 CAT.6 Properties: PUR halogen-free, flame-retardant, UV- resistant, chemical resistance, shielded (see www.samcon.eu Quicklink: https://www.samcon.eu/fileadmin/documents/en/60- Assembling%26mounting/ASKD02-T_Datasheet.pdf Figure 2-2 Sectional view of ASKD02-T 2.3.2 Connection cable for models with heater (SKDP03-T/ASKDP03-T) Systemcable SKDP03-T: Outside diameter: 12.40 ± 0.3 mm...

  • Page 8: Video-Technical Characteristics

    3G1.5 (BK-BU-GN/YE) Properties: PUR halogen-free, flame-retardant, UV- resistant, chemical resistance, shielded Quicklink: https://www.samcon.eu/fileadmin/documents/en/60- Assembling%26mounting/ASKDP03-T_Datasheet.pdf Figure 2-4 Sectional view of ASKDP03-T Video-technical characteristics We use the AXIS Q 1615 MkIII Network Camera in a pressure-resistant enclosure. For ® details, please refer to the Product Documentation, video-technical data of AXIS https://www.axis.com/products/axis-q1615-mkiii...

  • Page 9: Safety Instructions

    Camera Terminal box -10°C … +60°C -60°C … +55°C Permissible ambient temperature (for PoE power supply) -60°C … +60°C (In the event of additional 24 V DC power supply) Protection class as per EN IP68 IP66 60529/IEC 529 (Test conditions: 24h/3m water column 5°C) Housing material stainless steel, mat.

  • Page 10: Installation

    Please pay attention to the national and local regulations for mounting heavy loads. In case of doubt, take appropriate security measures. Drawings for drill hole patterns and further information can be viewed on our product page: Quick link: https://www.samcon.eu/en/products/roughcam/roughcam-ipq1615/ Doc.-ID: 210222-PT10BA-ES-RoughCam IPQ1615_en_rev.00.docx, Page 10 of 28...
  • Page 11 Optional mounting accessories WALL MOUNT BRACKET WMB-VA2.3 Wall bracket Wall bracket for devices of T10-VA2.3 series WMB-... Suitable for hanging the camera on walls. Material: stainless steel 1.4404 Load bearing: 45 kg Dimensions: 445 x 140 x 185 mm WEATHER PROTECTION ROOF WPR-VA2.3 Weather protec- Weathershield for cameras of the T10-VA2.3- tion roof...

  • Page 12: Electrical Connection

    Potential equalization Figure 5-1 RoughCam IPQ1615 Potential equalization Potential equalization/grounding of the camera housing is absolutely necessary, in order to avoid static charges and thus the formation of sparks. For this purpose, a screw termi- nal is provided at the rear side, at the bottom (right) (see Figure 5-1).

  • Page 13: Connection Work At The Device (Terminal Box) And Fuses

    IPQ1615. Possible terminations are: terminal box or plug. Figure 5-2 RoughCam IPQ1615 T10-VA2.3.K3.BOR2-N.H-xxx.N-T Figure 5-3 RoughCam IPQ1615 T10-VA2.3.K3.BOR2-N.H-xxx.N-P Video Tutorial: Observe our video tutorial: “SAMCON 01 Wiring the cable SKDP03-T to the junction box ExTB-3” https://go.samcon.eu/v01 Doc.-ID: 210222-PT10BA-ES-RoughCam IPQ1615_en_rev.00.docx, Page 13 of 28...
  • Page 14 Figure 5-4 Video Tutorial ExTB-3 The pin assignment of the SKD01-T is executed in accordance with the standard EIA/TIA-568B for 100BaseTX and 24VDC, as follows: Camera Colour Terminal Cross- Comment (T568B) SKD01-T sectional (IEC60757) surface WH / OG 0.32 mm Solid conductor 0.32 mm Solid conductor...
  • Page 15 The pin assignment of the SKDP03-T is executed in accordance with the standard EIA/TIA-568B for 100BaseTX and 24VDC, as follows: Camera Colour Terminal Cross- Comment SKDP03-T sectional (T568B) (IEC60757) surface WH / OG 0.26 mm Solid conductor 0.26 mm Solid conductor WH / GN 0.26 mm Solid conductor...
  • Page 16 SKD01-T SKD01-T RoughCam IPQ1645 Figure 5-5 Sample circuit of terminal box (without heater) Doc.-ID: 210222-PT10BA-ES-RoughCam IPQ1615_en_rev.00.docx, Page 16 of 28...
  • Page 17 RoughCam IPQ1645 Figure 5-6 Sample circuit of terminal box (heater integrated) Figure 5-7 Photo of the wired terminal box Doc.-ID: 210222-PT10BA-ES-RoughCam IPQ1615_en_rev.00.docx, Page 17 of 28...

  • Page 18: Fusing

    Bring the twisted pair composite up to about 10 mm close to the ter- minals, in order to ensure interference immunity. Attention! Use only terminals approved by SAMCON. Attention! Finally, check your network installation with a Class-D Link Test. 5.2.1 Fusing PoE power supply requires no fuses.

  • Page 19: Plug Assignments (Rj45)

    5.2.2 Plug assignments (RJ45) The data transfer of the RoughCam IPQ1615 series uses a 100 Mbit/s Ethernet connec- tion (100BASE-TX). If the cable termination uses a plug, the latter should be plugged into the RJ45 PoE slot of the network device (PSE). Prior to connecting it to the camera, the network device (PSE) can already be supplied with power, hence there is no „power ON“...

  • Page 20: Tests Prior To Switching On Voltage

    5.2.3 Tests prior to switching on voltage Attention! Prior to starting the device, perform all tests as indicated by the na- tional regulations. Furthermore, check the correct function and instal- lation of the device in accordance with this User Manual and other ap- plicable regulations.

  • Page 21: Opening The Housing

    Opening the housing If the RoughCam IPQ1615 is equipped with a weather protection roof this has to be re- moved prior to starting your work! To do so, loosen the 4x8mm lens screws M4*0.7 at the front and rear sides of the bracket holders (Figure 6-1).
  • Page 22 Figure 6-3 Opening the RoughCam IPQ1615 (similar illustration) Carefully pull out the cable and supply flange to the rear, as straight as possible. Be- cause of negative pressure, it may be difficult to remove the flange. Attention: The mounting adapter with the housing’s PTC heater, camera module and op- tics, as well as the temperature control, and (if applicable) auxiliary relays and terminal block are fixed on the cable and supply flange.

  • Page 23: Removing / Inserting A Sd Memory Card

    Removing / inserting a SD memory card Note: The RoughCam IPQ1615 has a slot for a micro SDHC memory card (card not included). Saved video files can be played and deleted via the web interface. They are also availa- ble in a download list. Moreover, the videos available in the memory card can also be accessed via FTP server in the network.

  • Page 24: Hardware Reset

    Hardware Reset To set all the parameters of the RoughCam IPQ1615 (including the IP address) to default values, you should run a hardware reset. The parameters can be reset via the web interface or manually. If the camera placed in the network can no longer be reached or its state is uncontrollable, the reset should be performed manually.

  • Page 25: Network Access And Visualization

    Assigning the IP address The RoughCam IPQ1615 is intended for use in an Ethernet network and requires an IP address to access and control it. In the most today’s networks, a DHCP server is inte- grated. This server automatically assigns an IP address.

  • Page 26: Password/ Identification

    Repairs may only be carried out with original parts of SAMCON Prozessleittechnik GmbH. In case of doubt, send the part in question back to SAMCON Prozessleittechnik GmbH. Rebuilding of or alterations to the devices are not permitted.

  • Page 27: Drawings & 3D Models

    Drawings & 3D models All drawings, 3D models, certificates and other information are available in the download area of the product page on our website: https://www.samcon.eu/en/products/roughcam/roughcam-ipq1615/ If you wish additional technical information, please contact us at: support@samcon.eu Doc.-ID: 210222-PT10BA-ES-RoughCam IPQ1615_en_rev.00.docx, Page 27 of 28...
  • Page 28 Schillerstrasse 17, 35102 Lohra-Altenvers, Germany www.samcon.eu, info@samcon.eu Phone: +49 6426 9231-0, fax: - 31...
