SERVICE MANUAL
EN
DEVILBISS SRi PRO SERIES:
SRi PRO Lite Gravity Spray Gun for micro, smart
repairs and small areas.
II 2 G X
IMPORTANT! DO NOT DESTROY
It is the Customer's responsibility to have all operators and service personnel read and understand this
manual.
Contact your local DeVilbiss representative for additional copies of this manual.
READ ALL INSTRUCTIONS BEFORE OPERATING THIS DEVILBISS PRODUCT.
1/24
SB-E-2-512 R2.0
