Check Point QUANTUM SPARK 1575R Getting Started Manual page 8

Power adapter: 120W (Industrial grade), operating within the temperature range of
l
o
40 to 70
Follow the SKU options in the catalogue.
3-Pin terminal block, 12V-60VDC and -48VDC, supplied by the customer's power
l
infrastructure
Power redundancy
l
Desktop, Wall mount and DIN rail mounts (2 types of assembly: rear and bottom)
n
n USB Type-C console port
n USB 3.0 port
n SD card support
ICS/SCADA protocol support
n
BACNet, CIP, DNP3, IEC-60870-5-104, IEC 60870-6 (ICCP), IEC 61850, MMS,
ModBus, OPC DA & UA, Profinet, Step7 (Siemens) and more; 1400+ in all.
See the full list at appwiki.checkpoint.com.
n Wi-Fi6 Cryptography: supports WPA (TKIP 128 bit) and WPA2 (AES, 128/256 bit)
n 3/4G/LTE Cryptography: supports NAS/AS security procedures and Snow 3G/AES/ZUC
security
n Certified to operate in harsh conditions
Industrial: IEEE 1613 , IEC 61850-3 , IEC 60945, EN/IEC 60529, heat and
l
immunity to electromagnetic interference
Rugged: EN/IEC 60529 , IEC 60068-2-27 shock, IEC 60068-2-6 vibration
l
Operating Temperature Range: -40ºC ~ 75ºC (-40ºF ~ 167ºF)
l
IP (Ingress Protection) Rating: IP30
l
Maritime
Certification: IEC-60945 B, IACS E10:1991 , DNV-GL 2.4 , DNV-GL-CG-0339, IEC 61162-
460
n Marine application: rated voltage 24 VDC, 12 VDC power input connector is not
applicable.
n Wall mount (for marine application).
n Operating temperature range: -40ºC ~ 70ºC for marine applications.
o
C
The Quantum Spark 1575R Appliance
Quantum Spark 1575R Appliance Getting Started Guide | 8
