Pepperl+Fuchs VisuNet EX2 GMP Series Hardware Manual page 9

VisuNet EX2 GMP RM/PC 3700 series
Safety
Rated voltage
Rated current
Maximum safe voltage U
Interface type 3
Connection
Rated voltage
Rated current
Maximum safe voltage U
Interface type 4
Connection
Voltage U
Current
Power P
Characteristic curve
Internal resistor
Lumped capacitances OR inductances
Interface type 5
Connection
Voltage U
Current
Power P
Characteristic curve
Internal resistor
Lumped capacitances AND inductances
Lumped capacitances OR inductances
Interface type 6
Connection
Voltage U
Current
Power P
Characteristic curve
Lumped capacitances OR inductances
m
m
o
I
o
o
o
I
o
o
o
I
o
o
±15 V
200 mA
60 V
USB (Ex nA)
X3: 5 ... 8
5 V
< 500 mA
60 V
USB (Ex ic)
X4: 1 ... 4
X4: 5 ... 8
4.95 V
234 mA
570 mW
trapezoid
41.6 Ω
C = 100 µF
o
L = 1 mH
o
USB (Ex ic)
X5: 1 ... 4
4.95 V
472 mA
1582 mW
trapezoid
33.2 Ω
C = 14 µF L = 5 µH
o o
C = 100 µF L = 0.3 mH
o o
TTY (Ex ib)
X5: 5 ... 8
9 V
150 mA
1.4 W
rectangular
C = 2.4 µF L = 3 mH
o o
9
