Table 2-2 Element descriptions (continued)
Element
Content
Camera
Poly Device Mode
Menu

Poly TC10 in Zoom Rooms Mode

In Zoom Rooms mode, the Poly TC10 can run either as a Zoom Rooms Controller or a Zoom Rooms
Scheduler.
NOTE: To use Zoom Rooms Controller and Scheduler, you need a Zoom Rooms account. To use
all of the functionality of the Zoom Rooms Scheduler, log in to the scheduler with a Zoom Rooms
admin account.

Poly TC10 as a Zoom Rooms Controller

Run Zoom Rooms Controller on a Poly TC10 positioned inside a conference room to launch and
manage Zoom meetings.
With Zoom Rooms Controller, a Poly TC10 in either paired or standalone mode controls the Zoom
Room. Once logged into the Zoom Room, you can join a scheduled meeting, start an unscheduled
meeting, invite participants to a meeting, view upcoming meetings, share content, dial a phone
number, and manage all aspects of a Zoom meeting.

Poly TC10 as a Zoom Rooms Scheduler

Run Zoom Rooms Scheduler on a Poly TC10 mounted outside a meeting room to manage the room.
The Poly TC10 displays the current status of the room and any scheduled meetings, and can be used
for room reservation.
Administrators can sync the following calendars to a Zoom Room:
Google Calendar
●
Office 365
●
Microsoft Exchange
●
Once synced, the calendar meetings for that day appear on the display.
Users can perform the following tasks on a Poly TC10 running Zoom Rooms Scheduler:
See the current status of the Zoom Room and any upcoming meetings
●
Reserve a time slot in the Zoom Room calendar
●
Reserve a time slot in another Zoom Room in an integrated floor plan
●
6 Chapter 2 Getting Started
Description
When content is available, the system displays a list of available content. Otherwise,
this function opens a help screen that describes how to set up content sharing using
HDMI, the Polycom Content App, or an AirPlay- or a Miracast-certified device.
Opens the camera control screen.
Launches Poly Device Mode, which allows you to use the Poly Video system as an
external camera, microphone, and speaker for your connected laptop.
Opens new menu selections for calling, sharing content, camera control, and
additional functions.
