SETUP INSTRUCTIONS
2023
890 SMT
Art. no. 3214899en

Advertisement

loading
Need help?

Need help?

Do you have a question about the 890 SMT 2023 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KTM 890 SMT 2023

Summary of Contents for KTM 890 SMT 2023

  • Page 1 SETUP INSTRUCTIONS 2023 890 SMT Art. no. 3214899en...
  • Page 3 KTM accepts no liability for delivery options, deviations from fig- ures and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that does not belong to the regular scope of supply.

  • Page 4: Means Of Representation

    1 MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips.
  • Page 5 To operate the vehicle, the vehicle electronics must be enabled. This process is conducted during initial setup in KTM Dealer.net. Enabling ensures that the initial setup in KTM Dealer.net is docu- mented. Enabling can be performed either temporarily, e.g. for a test ride, or permanently for vehicle handover.
  • Page 6 2 SETUP Info The procedure in the event of transport damage is described in the Customer Service Manual. – Remove cable ties and protective film on the handlebar. Warning Danger of accidents A repaired handlebar poses a safety risk. If the handlebar is bent or straightened, the mate- rial becomes fatigued.
  • Page 7 SETUP 2 – Mount the right hand guard. Guideline Hand guard fitting 6 Nm (4.4 lbf ft) Hand guard screw 25 Nm (18.4 lbf ft) F02129-01 – Mount the left hand guard. Guideline Hand guard fitting 6 Nm (4.4 lbf ft) Hand guard screw 25 Nm (18.4 lbf ft) F02130-01...
  • Page 8 2 SETUP Guideline Screw for throttle 3.5 Nm grip (2.58 lbf ft) Screw, combination 5 Nm (3.7 lbf ft) switch, right Info Pay attention to the markings on the handlebar. Make sure the cables and wiring are positioned cor- rectly. –...
  • Page 9 SETUP 2 – Mount reflector with rubber bushings and tension washers on the license plate holder – Position the license plate bracket on the license plate support. – Mount and tighten screws Guideline Screw, license 5 Nm (3.7 lbf ft) plate holder Loctite ®...
  • Page 10 2 SETUP – Remove the labels from the brake line and the frame. – Unpack and mount the KTM PowerParts included in the deliv- ery (optional). Info Read the accompanying KTM PowerParts fitting instruc- tions. – Attach the stickers included in the scope of supply (optional).
  • Page 11 WORK 3 Adjusting the handlebar position Warning Danger of accidents A repaired handlebar poses a safety risk. If the handlebar is bent or straightened, the material becomes fatigued. The handlebar may break as a result. – Change the handlebar if the handlebar is damaged or bent. –...
  • Page 12 3 WORK Mounting the passenger seat – Hook holding lugs of the passenger seat into the bushings on the subframe, lower the front, and simultaneously push back- ward. – Insert locking pin into the lock housing and push down the front of the passenger seat until the locking pin engages with an audible click.
  • Page 13 WORK 3 Main work – Remove left side cover from the rubber bushings in the areas – Pull off the left side cover sideways and remove it toward the front. I00385-10 Opening the storage compartment on the left Preparatory work –...
  • Page 14 3 WORK Closing the storage compartment on the left Main work – Close the storage compartment. – Raise elastic fastener and hang up in area F01899-10 Finishing work – Install the left side cover. ( p. 12) – Mount the seat. ( p.
  • Page 15 WORK 3 3.10 Removing the right side cover Preparatory work – Remove the seat. ( p. 10) Main work – Remove the side cover from the rubber bushings in areas – Pull off the right side cover sideways and remove it toward the front.
  • Page 16 3 WORK 3.12 Closing the storage compartment on the right Main work – Close the storage compartment. – Raise elastic fastener and hang up in area F01901-10 Finishing work – Install the right side cover. ( p. 14) – Mount the seat. ( p.
  • Page 17 WORK 3 3.14 Removing the battery cover Preparatory work – Remove the seat. ( p. 10) Main work – Remove screws with the bushings. – Remove the battery cover from above. I00389-10 3.15 Installing the battery cover Main work – Position the battery cover with holding lugs bushings and push downward.
  • Page 18 3 WORK Note Environmental hazard 12 V batteries contain environmentally hazardous materials. – Do not dispose of 12 V batteries as household waste. – Dispose of 12 V batteries at a collection point for used batteries. Note Environmental hazard Hazardous substances cause environmental damage. –...
  • Page 19 WORK 3 3.17 Disconnecting the negative cable of the 12-V battery Warning Risk of injury Battery acid and battery gases cause serious chemical burns. – Keep 12 V batteries out of the reach of children. – Wear suitable protective clothing and safety glasses. –...
  • Page 20 3 WORK Caution Danger of accidents Electronic components and safety devices will be damaged if the 12-V battery is dis- charged or missing. If the 12-V battery is discharged or defective, malfunctions in the vehicle electronics can occur, espe- cially when starting. –...
  • Page 21 WORK 3 3.21 Checking the headlight setting – Park the vehicle on a horizontal surface in front of a light- colored wall and make a mark at the height of the center of the low beam headlight. – Make another mark at a distance under the first marking.
  • Page 22 3 WORK 3.23 Installing the left tank guard – Position the tank guard. – Mount and tighten screws Guideline Screw, trim 3 Nm (2.2 lbf ft) I00420-10 3.24 Removing the left tank guard – Remove screw – Remove the tank guard. I00420-10 3.25 Installing the right tank guard...
  • Page 23 WORK 3 3.27 Refueling Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not fuel the vehicle in the vicinity of open flames or lit cigarettes. – Switch off the engine for refueling.
  • Page 24 3 WORK 3.28 Opening the fuel tank filler cap Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not fuel the vehicle in the vicinity of open flames or lit cigarettes. –...
  • Page 25 WORK 3 Warning Fire hazard Fuel is highly flammable and a health hazard. – Check that the fuel tank filler cap is locked cor- rectly after closing. – Change your clothing if fuel spills on them. – Rinse the affected area immediately with plenty of water in the event of contact with the skin.

  • Page 26: Technical Specifications

    4 TECHNICAL SPECIFICATIONS chassis tightening torques Brake fluid reservoir cover, front 2 Nm (1.5 lbf ft) Brake fluid reservoir cover, rear 1.5 Nm (1.11 lbf ft) Compensating tank cover 1.1 Nm (0.81 lbf ft) Nut, valve ISO 10V2 12 Nm (8.9 lbf ft) Loctite ®...
  • Page 27 TECHNICAL SPECIFICATIONS 4 Screw, license plate holder 5 Nm (3.7 lbf ft) Loctite ® 243™ Screw, lower rear panel 3 Nm (2.2 lbf ft) Screw, mask support 5 Nm (3.7 lbf ft) Screw, mask support cover 3.5 Nm (2.58 lbf ft) Screw, side stand sensor 2 Nm (1.5 lbf ft) Loctite...
  • Page 28 4 TECHNICAL SPECIFICATIONS Screw, fuel pump 6 Nm (4.4 lbf ft) Screw, fuel tank clamp 3 Nm (2.2 lbf ft) Screw, fuel tank spoiler attach- 4 Nm (3 lbf ft) ment Screw, fuel tap 6 Nm (4.4 lbf ft) Screw, ground wire on frame 6 Nm (4.4 lbf ft) Screw, ground wire on starter 10 Nm (7.4 lbf ft)
  • Page 29 TECHNICAL SPECIFICATIONS 4 Screw, handlebar clamp 20 Nm (14.8 lbf ft) Screw, main silencer fastening 15 Nm (11.1 lbf ft) Screw, main silencer holder 25 Nm (18.4 lbf ft) Screw, passenger seat bracket 25 Nm (18.4 lbf ft) Loctite ® 243™...
  • Page 30 4 TECHNICAL SPECIFICATIONS Bushing, shock absorber support M20LHx1.5 10 Nm (7.4 lbf ft) Thread and fitting greased Screw, steering head M20x1.5 18 Nm (13.3 lbf ft) Nut, rear wheel spindle M25x1.5 90 Nm (66.4 lbf ft) Thread and contact area of wheel spindle greased Screw, front wheel spindle M25x1.5...
  • Page 31 SUBSTANCES 5 Super unleaded (ROZ 95) Standard/classification – DIN EN 228 (ROZ 95) Guideline – Only use super unleaded fuel that matches or is equivalent to the specified standard. – Fuel with an ethanol content of up to 10% (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.g., M15, M85, M100) or more than 10% ethanol (e.g., E15, E25, E85, E100).
