Appendix D: Serial Command Reference
FRF) FREE RUN FREQUENCY (Cont'd)
(
EXAMPLES:
(FRF 5000) - Set free run frequency to 50 Hz.
(FRF ?) - Get free run frequency.
FRZ) FREEZE IMAGE
(
Unsaved
CONTROL GROUP:
DESCRIPTION
Freeze the display image. This allows a detailed examination of a single frame of an otherwise moving image.
Switching channels/Inputs automatically switches the projector to unfrozen.
SUBCODE
MAIN
PIIP
EXAMPLE:
(FRZ+MAIN 1) - Freeze the main image.
GAM) GAMMA CORRECTION
(
Preference
CONTROL GROUP:
DESCRIPTION
The Gamma Correction control is used to correct ambient conditions affecting the display. The Gamma control
affects the shape of the curve determining what grey shades are displayed for a given amount of signal Input
between minimum (black) and maximum (white). This is done by performing a linear transform from the user
selected gamma channel setting. The normal point is 0, meaning the selected gamma table is used unaltered. If
there is a lot of ambient light, the image can become washed out, making it difficult or impossible to see details in
dark areas. Increasing the gamma correction setting can compensate for this by transforming the curve towards a
gamma of 1.0. Decreasing the control shall transform the gamma towards a gamma of 3.0.
SUBCODE
<No Subcode >
EXAMPLES:
(GAM 100) - Set gamma to 1.0 curve.
(GAM?) - Returns current gamma curve.
(GIA) ANALOG BNC GROUNDED INPUT SELECTION
Option
CONTROL GROUP:
DESCRIPTION
Set the Input signal grounding method to single-ended or differential. Valid values are:
0 = Differential (default)
1 = Single-ended
D-28
Power Up
SUBCLASS:
DESCRIPTION OF USE
Freeze or un-freeze the main image (1=freeze, 0=unfreeze)
Freeze or un-freeze the main image (1=freeze, 0=unfreeze)
Power Up
SUBCLASS:
DESCRIPTION OF USE
Set the interpolated gamma level
Power Up
SUBCLASS:
Operator
ACCESS LEVEL:
Operator
ACCESS LEVEL:
Operator
ACCESS LEVEL:
.
