B+B Pyro Light Manual page 30

PYRO LIGHT PYRO LIGHT / XL
| Lightweight wheelchair | Leichtgewichtrollstuhl
PYRO LIGHT XL
2.4. Participation in road traffic
The wheelchair is designed for indoor and outdoor use. Please note
that you are participating in public road traffic and must comply
with the regulations of the Road Traffic Act. Do not endanger other
participants by driving recklessly, this applies especially on
pavements.
2.5. Brakes
Operating brake:
When driving, brake the wheelchair by using the handrims. Please note
that your hands may get hot.
Parking brake/parking:
As soon as the wheelchair is stationary, push both levers of the knee
lever brake forward (see chapter 5.14). The wheelchair is safely braked
when it can no longer be pushed away and both levers are pushed
forward as far as they will go.
Pull the levers back towards you to release the brake (see chap. 5.14).
The locking levers located on the brake levers for the drum brake can
also be used to lock the drum brake for parking (chap. 5.17).
Drum brake:
The wheelchair can be optionally equipped with a drum brake, which
can only be operated by an attendant via the brake levers on the push
handles.
The brake levers on the push handles only act on one drive wheel at a
time! Always use both brake levers to brake the wheelchair.
59 59
Leichtgewichtrollstuhl | Light weight wheelchair |
2.6. Indications
Inability to walk or severe walking disability in adults due to
• Paralysis
• Limb loss
• Limb defect / deformity
• Joint contractures / joint damage (not on both arms)
• Other diseases
Use with reinforced wheelchairs is indicated when the body weight of
the disabled person is 125 kg or more and a standard wheelchair no
longer provides the necessary safety.
2.7. Contraindications
The use of the wheelchair by adults is unsuitable in the case of
• Perceptual disorders
• Severe balance disorders
• Loss of limbs on both arms
• Joint contractures / joint damage in both arms
• Incapacity to sit
• Reduced or insufficient vision
2.8. Declaration of conformity
We Bischoff & Bischoff GmbH declare under our sole responsibility
that the Pyro Light / Pyro Light XL wheelchair complies with all
requirements of MDR 2017/745 that are applicable.
Bischoff & Bischoff GmbH | 2021-07-26 - Revision 1 Bischoff & Bischoff GmbH | 2023-09-01 - Revision 2
PYRO LIGHT / XL PYRO LIGHT
PYRO LIGHT XL
60 60
