Bison BA894GCSTL Instruction Manual

Portable/adjustable basketball systems

Advertisement

Quick Links

Portable/Adjustable Basketball Systems
BA894GSR, BA894USR,BA894GCSTL, BA894UCSTL and Sportmaster 4.5
P A R T S L I S T
Item
Qty
Description
A
1
Portable Base
B
2
Foot Pad
C
2
"L" Bracket
D
4
3/8" X 4 1/2" Hex Bolt
E
2
Backboard Braces (1 right, 1 left)
F
4
3/8" x 1" Hex Bolt
G
8
3/8" Flat Washer
H
4
3/8" Lock Washer
I
4
3/8" Hex Nut
J
1
Backboard
K
1
Backboard Hardware (Included in J above)
Do not remove the safety strap until the backboard and goal installation is complete. This unit is under
extreme spring tension and severe injury and damage will result.
¨
Inspect all contents prior to installation. Report any missing parts to dealer immediately.
¨
NEVER SUBSTITUTE LOCALLY SOURCED COMPONENTS FOR MISSING, LOST, OR DAMAGED FACTORY COMPONENTS.
¨
Carefully read all instructions before proceeding. Pay special attention to all safety instructions.
¨
Save this instruction in the event that the manufacturer must be contacted in the future for maintenance information.
While gym floor installers and refinishers often indicate floors are OK to walk or play on in 7-10 days
after oil based polyurethane finishes are applied, in reality, it can actually take up to 30 days for all the
chemicals in the polyurethane to dissipate. Chemical reactions between the floor finish and certain
materials including urethane feet contacting the floor can cause permanent discoloration. Placement of
this product on floors prior to the 30-day final cure period may risk discoloration that would not be
1.
Carefully lift the front of the Portable Base (A) with a forklift or 4 adults until the back wheels make
contact. Remove and discard the shipping pallet. Install the Foot Pads (B) and then tighten the Jam Nuts
(T) against the top of the Foot Pads (B). See Figure 1.
2.
Make sure Portable Base (A) is on a level floor. It is best to finish assembly on the floor where the
Portable Base (A) will actually be used.
Implementation Date: 2/12/25
—— Instruction Manual ——
4 1/2' Safe Play Area
(PC3670)
(FT1668)
(FT1541)
(FT1950)
(FT1960)
(FT1080)
covered by the manufacturer's warranty.
Rev: 10
N.J.C.
Item
Qty
Description
L
1
Breakaway Goal
M
1
Breakaway Goal Hardware (Included in L above)
N
1 set
Pads (front, side, and arm)
O
20
1/4"-20 x 3/4" Flat Head Screw
P
2
Locator Pin
Q
10
Padding Bracket
R
2
Floor Bushing
S
1
Rachet Wrench (PC3554)
T
2
Jam Nut - FT1192
U
2
Lock Collar - PC1936
V
2
Protective Rubber Cap - PC1215
WARNING!
NOTICE:
File: I:\Pub\Inst\Port.sys\BA894G
1
Assembly Video
(FT1288)
Ref#:930469
L.M.

Advertisement

loading
Need help?

Need help?

Do you have a question about the BA894GCSTL and is the answer not in the manual?

Questions and answers

Summary of Contents for Bison BA894GCSTL

  • Page 1 —— Instruction Manual —— Portable/Adjustable Basketball Systems BA894GSR, BA894USR,BA894GCSTL, BA894UCSTL and Sportmaster 4.5 4 1/2’ Safe Play Area Assembly Video P A R T S L I S T Item Description Item Description Portable Base Breakaway Goal Foot Pad (PC3670) Breakaway Goal Hardware (Included in L above) “L”...
  • Page 2 Start with the hex head of the backboard leveling bushings on the lower front of the extension arm threaded up against the rear of the backboard mounting plate. See Figure 2. Figure 2 Figure 1 WARNING! Step 4 requires 2-3 strong adults for safe installation. Mount the Breakaway Goal (L) and the Backboard (J) using 3/8”x 4 1/2”...
  • Page 3 NOTICE: Never raise or lower front leveling pads with power tools as it will cause damage to the adjustment screw and nut resulting in unit failure. Regularly apply a heavy grease lubricant to adjustment screw threads. Measure the Breakaway Goal (L) height and, if necessary, adjust the two front Foot Pads (B) up or down equally as needed to get the front of rim to an official 10' height using the Ratchet...
  • Page 4 FIGURE 7 FIGURE 8 18. Attach Backboard Braces (E) to the extension arm with 3/8" x 1" Hex Bolts (F), Flat Washers (G), Lock Washers (H) and Hex Nuts (I). Attach Backboard Braces (E) to the "L" Brackets (C) with 3/8" x 1" Hex Bolts (F), Flat Washers (G), 3/8"...
  • Page 5 NOTE: The locator pins and floor bushings are an included user option for repeat positioning of the unit in reference to a playing surface and to eliminate side shift during aggressive play. FIGURE 10 FIGURE 11 FIGURE 13 FIGURE 12 Carefully drill 7/8"...
  • Page 6 24. Although designed with adequate ballast for safe play, the back of the unit might bounce slightly with excessive hanging. If you want additional stability during heavy play purchase optional BA898HD2 Portable Hold Down Kit to anchor the rear of the unit to the floor. 25.
