PRODUCT SPECIFICATION (RAW 1.7 DMX+ILDA)
Product Name:
Type Of Laser:
Guaranteed Optical Output:
Suitable For:
Control Signal:
Scanning System:
Scan Angle:
Safety:
Weight:
Package Includes:
R | G | B [mW]:
Beam Size [mm]:
Beam Divergence:
Modulation:
Power Requirements:
Consumption:
Operation Temperature:
Ingress Rating:
System Features:
Laser Safety Features:
Notice:
Dimensions [mm]:
Unity RAW 1.7 (DMX+ILDA)
Full-colour, Semiconductor diode laser system
>1.8W
Clubs, DJs, smaller indoor venues, home and hobby use. Beam show,
text, graphic, and mapping capable
DMX mode, sound active mode, and ILDA mode (we recommend
Pangolin FB3QS and QuickShow for ILDA control)
35,000 points per second @ 8°
50°
Fully complies with the latest EN 60825-1 and FDA regulations
5.3kg
Laser projector, Estop box, Estop cable (10M/30ft), ILDA cable (10M/30ft),
power cable (1.5M/4.5ft), interlock, keys, manual, quickstart guide,
variance card, carton packaging (* service dongle if outside US)
350 | 500 | 1,000
5 x 3
<1.1mrad [Full Angle]
Analog 50kHz
100-230V/50Hz
Max. 100W
10-40 °C
IP4X
Adjustments for color channels (R,G,B), size/position/invert (X,Y), DMX in/
out, ILDA in/out, Estop in/out, power in/out, sound active mode, digital
display for DMX address and settings
Keyed interlock, Emission delay, Magnetic interlock, Scan-fail safety,
Mechanical shutter, Adjustable aperture masking plate
*Due to Advanced Optical Correction technology used in our laser
systems, each laser colour's optical power output may slightly differ from
the specification of the respective laser module(s) installed. This does
not affect the total guaranteed power output
Depth: 238
Width: 192
Height: 126
