Caution – use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
This Laser Product is designated as Class 4 during all procedures of operation.
REMINDER: In the United States, this laser product may not be purchased, sold, rented, leased or loaned for
use unless the recipient possesses a valid Class 4 laser light show variance from the US FDA CDRH.

OPERATION

CONNECTING THE LASER SYSTEM

1. To control the system with an external signal such as Ethernet or ILDA, plug the corresponding cable into
its designated connector at the back of the unit.
2. Connect the Emergency STOP remote to the socket labled as a "Remote Input" with the supplied 3-pin
XLR cable.
3. Insert the Remote Interlock Bypass to the E-STOP Remote to disable the interlock (USA only).
4. Use supplied Neutrik powerCON power cable to connect the laser system to a main power supply usign
the input connector.
INSERT THE SAFETY KEYS
1. Turn the laser system key to the on position.
2. Turn the E-STOP remote key to the on position.
DISABLE THE INTERLOCK
1. Release the E-STOP button by pulling upwards.
2. Press the START button on the E-STOP remote.

TURNING OFF THE LASER SYSTEM

1. Turn off the key switch; and deactivate via the red mushroom switch on the E-stop box. You can remove the
3-pin Interlock bo too, if the laser will be kept for no use. (We recommend having a professional operator
to keep the keys and 3-pin Interlock switch.)
2. Turn off the power to the projector via the power switch.
