OPERATION [CONTINUED]
DMX EXPERT MODE CHANNEL INSTRUCTIONS CH18-CH34
Channel
X-wave
CH18
Y-wave
CH19 Strobe
CH20 Pattern size
CH21 X-axis position
CH22 Y-axis position
CH23 Choose show
CH24 Color
Line scanning
CH25
Dot scanning
CH26 Show list
CH27 Z-rotation
CH28 X-rotation
CH29 Y-rotation
CH30 X-moving
CH31 Y-moving
CH32 Zooming
CH33 Drawing
X-wave
CH34
Y-wave
Type Value
1-127
128-255
1-255
0-255
0-255
0-255
0-255
0-63
64-95
96-127
128-159
160-191
192-233
224-255
0-127
128-255
0-255
1-127
128-255
1-127
128-255
1-127
128-255
1-127
128-255
1-127
128-255
1-127
128-255
1-255
1-127
128-255
Raw 1.7/3/5/10 (DMX+ILDA) Operational Manual (Revision 2024-11)
Select X waving speed
Select Y waving speed
Strobe speed, from slow to fast
Select pattern size
Change X-position, value 128 is the middle position.
(valid only when CH3 is selected 1-255)
Change X-position, value 128 is the middle position.
(valid only when CH3 is selected 1-255)
Select a show for every 2 values (CH26 selected a
show list)
Select single color
Fixed color/color changing effect speed selection
Color changing effect speed selection
Color changing effect speed selection/flowing color
effect speed selection
Flowing color effect speed selection
Flowing color effect speed selection
Color drawing effect speed selection
Scan speed selection
Scan speed selection
Select a show list every 8 values (value 0 selects all
lists)
Select rotation angle
Select rotation speed
Select rotation angle
Select rotaiton speed
Select rotation angle
Select rotaiton speed
Select moving position
Select moving speed
Select moving position
Select moving speed
Select zooming size
Select zooming speed
Select drawing speed
Select X waving speed
Select Y waving speed
19
Function
