Assa Abloy 540F Installation Instructions page 4

Outside Door Face Trim Template
3-5/8
(92)
1-3/8
(35)
1-3/8
(35)
"C"
(2) 3/8 (9.5) Dia
x 1/2 (13) Deep 7/32
(5.5) Dia Thru
3-5/8
(92)
Dimensions given in
Inches
(mm)
1-800-235-7482 • www.assaabloy.com
Copyright © 2019, 2023, 2024, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
LHR TRIM
"x"
11/16
(17.5)
"A"
2-1/8 (54) Dia
x 7/8 (22) Deep
C L
HORIZONTAL
REFERENCE
"B"
1/2
Dia Thru
(13)
C L VERTICAL
REFERENCE
C L
(Device Trim)
See Chart
2 "X" HOLES
(for 581F, 586F, 588F,
& 589F ONLY)
"x"
TRIM
541F, 546F, 548F, 549F
581F, 586F, 588F, 589F
For Holes Marked "X" See Below
METAL DOORS:
Inside Face 5/16" (8) Dia.
Outside Face 1/16" (13) Dia.
WOOD DOORS: 1/2" (13) DIA. THRU
CAUTION: Office printers, copiers and facsimile
machines may change the size of a drawing
and make the template inaccurate to use as a
door marker. If this is not the original template
packed with the trim, use only the holes on the
door (do not use template as a door marker).
HOLES
A, B, C
A, B, C, X
80-8470-0541-000 01/24
