04_ETC_310_EN1
13/07/05

Safety

The television's components are sensitive to heat.The maximum ambient temperature should not exceed 35° Celsius.
Do not cover the vents at the back or sides of the television.
Leave sufficient space around it to allow adequate ventilation.
Damp in rooms where the set is installed should not exceed 85% humidity.
If you have to use the television outdoors, do not expose it to water from rain or splashing.
Therefore be careful not to place any object containing a liquid (vase, glass, bottle,...) on or near your appliance.
Moving it from a cold atmosphere into a warm one can cause condensation on the screen (and on some components inside the television).
Leave the condensation to evaporate before turning the television on again.
If you are away for a long period, switch the set off at the on/off switch.
Even when off, some components remain in contact with the mains electricity supply.
To completely isolate it you must remove the plug from the mains supply socket.
According to the model dependent, the on/off switch is located at the front or side of the television.
During thunder storms, we recommend that you disconnect the television from the mains and aerial so that it is not affected by
electrical or electromagnetic surges that could damage it.
For this reason, keep the mains socket and aerial socket accessible so they can be disconnected.
Immediately disconnect the television if you notice it giving off a burning smell or smoke.
You must not under any circumstances open the television yourself.
You are at risk of electrocution if you do so.
The set is provided with adequate shielding to avoid the emission of X-rays.
Work by unqualified persons, modifications to the high voltage or replacement of the tube by a model not complying with the
manufacturer's recommendations may cause a sharp increase in X-ray emissions.
A set modified in this way no longer meets the original specifications and should not be used.
Precautions to be taken with TV sets/ monitors

Care

Clean the screen with a glass care cleaner and the rest of the set with a soft cloth and neutral detergent.
Regularly dust the vents at the back or sides. Using solvents, abrasive or alcohol based products risks damaging the television.

Demagnetization

Badly shielded loudspeakers or other strong magnetic fields near the TV can cause patches of colour to appear on the screen.
Move any magnetised materials away from the TV, switch the set off and switch it on fifteen minutes later.
Before setting up your television set, make sure that the surface you want to put the set on can support its weight
(see the list of specifications provided with the booklet).
Don't place the set on an unstable surface (e.g. moving shelf, very edge of a unit) and make sure that the front of the
television set does not overhang the surface it is sitting on.
THOMSON is not liable if the television is used other than in accordance with this manual.
In our efforts to improve the quality of our products, we reserve the right to change their features.The information contained in these instructions are
therefore liable to change and are not contractual.
11:50
Page 1
(Noir/Process Black film)
The pages of this publication are printed on recycled paper
1

Precautions

EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETC310 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for THOMSON ETC310

  • Page 1: Precautions

    (see the list of specifications provided with the booklet). Don’t place the set on an unstable surface (e.g. moving shelf, very edge of a unit) and make sure that the front of the television set does not overhang the surface it is sitting on.
  • Page 2: O Specific Precautions For Projection Tvs

    In order to ensure long performance of your set and reduce the risk of screen burning, please observe the following precautions. - Do not display still images (still computer and video game images, logos, pictures, text and images displayed in 4:3 format on 16:9 sets) for extended periods of time;...
  • Page 3: Table Of Contents

    Optional functions are indicated by the following Manual set-up ..............15 symbol: O The model number of your TV set is on a label at the back of the set and on the cover of this manual. You can contact THOMSON by dialling: 0871 712 1312 (for United Kingdom, £0.10 / mn inc VAT)
  • Page 4: Remote Control

    - in digital mode, simply enter the digits one after the other. Selecting a device connected to an AV connector. Important: If the remote control batteries are flat, you can use the buttons on the front of the television set which have the same functions as the remote control keys.
  • Page 5: Using The Remote Control With Other Devices

    Using the remote control with other devices This remote control allows you to control other devices by using the programmable keys VCR , DVD , SAT , AMP and AUX . Here is the list of devices that you can control with these keys:...
  • Page 6: Manual Programming

    Press the corresponding key on the remote control, and while holding it down, enter one of the codes that corresponds to the manufacturer of the device (list of brand codes are found at the end of this document). If the light or keys flash, you have entered an incorrect code or the programming is not possible.
  • Page 7: Switching On

    (Noir/Process Black film) Switching on Follow the instructions on this page to use your TV set and the remote control unit before entering the channel set-up procedure described on the next page. Insert two LR06 or AA batteries in the remote control.
  • Page 8: Digital Reception

    When turning on the TV for the first time, a menu giving the choice of languages appears. If it is not the first time the set has been turned on, see the paragraph Later Set-ups (see below).
  • Page 9: Additional Functions

    The first time it is modified, only steps 2 to 4 are necessary. We recommend that write down your new PIN code and keep it in a safe place. If you lose it, you can reset your receiver to the factory defaults but you will lose all the information that you have previously saved.
  • Page 10: Configuration Of The Receiver

    1. Select settings and press the OK key. - SPDIF output: Press the Right key and ON the SPDIF output, in order to be able to connect a Digital Audio amplifier to the Digital out socket located at the rear of the set.
  • Page 11: Parental Control

    The list of channels is displayed. 1. Using the Up / Down keys, select the channel to be locked. 2. Press the Green key to lock or unlock the channel, a symbol is displayed in front of the chan- nel name when it is locked.
  • Page 12: Programming

    Press the EXIT key to cancel the automatic channel change. TV ON/OFF :The timer will turn on and turn off the television set (if it is on standby) at the programmed time (set start time and stop time, see below).
  • Page 13: Analogue Reception

    When turning on the TV for the first time, a menu giving the choice of languages appears. If it is not the first time the set has been turned on, see the paragraph Manual Installation to run an Automatic Installation.
  • Page 14: O Adjusting The Convergence

    It occasionally happens that after a certain period of operation or as a result of vibration (if you have moved the television, for instance), the convergence goes out of alignment.This results in coloured contour appearing around people and objects, requiring the convergence to be adjusted.This...
  • Page 15: Manual Set-Up

    Analogue reception – Manual set-up The information provided on this page is useful if you find that some channels have not been stored during the initial set-up or automatic update processes.This can happen if you are setting up cable network channels.
  • Page 16: Everyday Use

    Putting the set on standby: press the Standby key on the remote control. The red light on the front of the set remains lit. The TV is under power and consumes a small amount of electricity. To leave standby mode...
  • Page 17: Selection Of Channels Or Radio Stations

    - Via the PR+ / PR- keys: scroll through the channels or radio stations. AV programmes are not included in this loop but can be accessed using the PR +/ PR – keys of the television set or the AV key on the remote control.
  • Page 18: Setting The Time - List Of Programmes

    (Noir/Process Black film) Setting the time – List of programmes The information on this page explains how to use the TIME menu functions (Setting the time, Sleep timer,Wake-up), as well as tho- se for the LIST OF PROGRAMMES menu. Timers (Analogue reception only) OVERVIEW Display the OVERVIEW menu using the MENU button and select the Timers option.
  • Page 19: Picture And Preferences

    Country: the choice of country is important for the correct display of Teletext screens in the corresponding language. Picture Rotation: this option is only available on 16/9 and 4/3 large screen televisions. It is used to compensate the effects of the earth’s magnetic field and to produce a perfectly aligned horizontal picture.
  • Page 20: Sound Setting - Ovirtual Dolby Surround

    Dolby Virtual is a technology certified by Dolby Laboratories, that creates a virtualized surround sound experience from two speakers.The Virtual Dolby Surround function works in multi-channel and Dolby Surround encoded audio sources. Virtual Dolby Surround retains all of the original multichannel audio information and provides the listener with the sensation of being surrounded by additional speakers.
  • Page 21: Teletext

    ZOOM in the bottom left window of the page and press OK, once to enlarge the top of the screen, twice to enlarge the bottom of the screen, or three times to restore the original size. Mixed screen: to overlay a teletext page onto the channel picture, using buttons select MIX in the bottom left window of the page and confirm with OK.
  • Page 22: O Program Info

    “No Program Info data found on this station.” will come up on the screen, press OK to access menu PROGRAM INFO SET -UP. Select line TV guide page number and with the number keys of your remote control, enter the number of the programme page which you have previously searched for in the teletext.
  • Page 23: Other Connections

    (see “More info“).The push button located on the side allows the module to be extracted. Digital audio socket (Digital out) Located at the rear of the television set, it allows it to be connected to a digital audio ampli- fier.
