THOMSON TX807 C/CS
Adjustments
Service Mode
It is necessary to enter the Service Mode in 3.2 The values will be stored in the non-volatile
order to carry out alignment of the TV set. Most memory when leaving the service menu.
adjustments can be made with the RCU, except 3.3 To leave the service menu press the "Exit"
the Focus and Screen voltages.
button on the RCU.
1. Service Mode Access
4. Temporary exit from Service Mode
1.1 With the RCU, switch the TV set into the
4.1 To temporarily leave the Service Mode,
"Standby' mode.
press the "Exit" button on the RCU. To access
1.2 Switch "Off" the TV set by mains supply
the everyday menus, press the "Menu" button
switch (wait until LED is dark).
on the RCU.
1.3 Whilst pressing the "Magenta (text)" button
4.2 To retum to the Service Menu, press the
on the RCU switch "On" the TV set using the
"Magenta" button on the RCU.
mains switch.
Continue to press the "Magenta (text)" button
5. Leaving the Service Mode
until the Service-setup Sub-menu appears.
5.1 To leave the Service mode either, switch the
TV set into "Standby" or switch "Off" the mains
supply.
2. Service Menu
2.1 Navigation
- Press the / buttons to select the menu
line.
- Press the / buttons to make adjustments
or selection of a menu item.
2.2 Service Sub-Menus
Set-up lines (INIT, STANDARD, OSDCONTR) -
Geometry lines (HS,VS,VA,SC,VSH)
Video lines (CL, BLORS/BLORP, BLOGS/
BLOGP,WPPRS/WPRP,WPGS/WPGP, WPBS/
WPBP, PWS/PWP, BKS,YD) -
IF lines (TOP) -
Video Processor (CD0, CD1, SYN0, SYN1,
DEF, VI0, VI1, SOUND, CONT0, CONT1,
FEAT0).
2.3 Activation of a line:
The first line (1) is continuously displayed.
Sequential selection of the others is possible by
pressing the / buttons on the RCU. The
selected line will be highlighted in YELLOW text.
3. Alignment and storing new function value
3.1 The current value of the selected funcfion is
displayed in a hexadecimal form to the right of
the function name. This value is adjusted by
means of the RCU / buttons.
Alignments
