- Page 1 Maya2000, Maya 2000Pro, and Maya2000Pro VIS-NIR Spectrometers Installation and Operation Manual Document Number 020-00000-000-02-201207 Offices: Ocean Optics, Inc. World Headquarters 830 Douglas Ave., Dunedin, FL, USA 34698 Phone 727.733.2447 727.733.3962 8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST E-mail: Info@OceanOptics.com...
- Page 2 Every effort has been made to make this manual as complete and as accurate as possible, but no warranty or fitness is implied. The information provided is on an “as is” basis. Ocean Optics, Inc. shall have neither liability nor responsibility to any person or entity with respect to any loss or...
-
Page 3: Table Of Contents
Interface ........................4 Shipment Components ....................5 Other Accessories Available ..................5 Breakout Box ..........................6 Chapter 2: Installing the Maya2000 Series Spectrometers ..... 7 Overview ........................7 Maya2000 Series Installation ..................7 Configuring the Maya2000 Series Spectrometers ............8 Connect Spectroscopic Accessories ................ - Page 4 Table of Contents Chapter 3: Troubleshooting .............. 9 Overview ........................9 Maya2000 Series Spectrometers Connected to Computer Prior to Software Installation 9 Windows Operating Systems ....................9 Remove the Unknown Device from Windows Device Manager ........... 9 Remove Improperly Installed Files ..................10 Mac Operating Systems ......................
-
Page 5: About This Manual
About This Manual Document Purpose and Intended Audience This document provides the user of a Maya2000 Series Spectrometer with instructions for setting up, calibrating and performing experiments with their spectrometer. What’s New in this Document This version of the Maya2000 and Maya2000Pro and Maya2000Pro VIS-NIR Installation and Operation Manual updates the models offered. -
Page 6: Upgrades
Resources CD that ships with the product. Upgrades Occasionally, you may find that you need Ocean Optics to make a change or an upgrade to your system. To facilitate these changes, you must first contact Customer Support and obtain a Return Merchandise Authorization (RMA) number. -
Page 7: Chapter 1: Introduction
The Maya2000 Series’ onboard module has 10 user-programmable digital I/O lines for interfacing to other equipment; and a pulse generator for triggering other devices. You can use the I/Os to flash a lamp, stop/start a process, and send a message/alarm during the spectrometer’s integration period. -
Page 8: Models
Maya2000 Series Spectrometers. Models The Maya2000 Series Spectrometers consist of three models, the Maya2000 and the Maya2000 Pro, and the Maya2000Pro VIS-NIR. The Maya2000 has been discontinued. While these spectrometers have similar performance for most parameters, the Maya2000 has slightly faster readout time, and the Pro offers better dynamic range and signal-to-noise. -
Page 9: System Requirements
30-pin connector for interfacing to external products • CE certification System Requirements You can use the Maya2000 Series’ USB connectivity with any computer that meets the requirements for the spectrometer operating software being used (Windows 98/Me/2000/XP, Mac OS X and Linux). See About SpectraSuite Software. -
Page 10: Sampling System Overview
Interface The Maya2000 Series has a USB connector, enabling you to connect the spectrometer to a desktop or notebook computer via a USB port. SpectraSuite software is available to operate your spectrometer for an additional charge. -
Page 11: Shipment Components
Software and Technical Resources CD Each order ships with the Ocean Optics Software and Resources CD. This disc contains software, operating instructions, and product information for all Ocean Optics software, spectrometers, and spectroscopic accessories. You need Adobe Acrobat Reader version 6.0 or higher to view these files. -
Page 12: Breakout Box
22-pin port to an array of standard connectors and headers, enabling easy access to a variety of features found in Ocean Optics’ Maya2000 Series Spectrometer. In addition to the accessory connector, the breakout box features a circuit board based on a neutral breadboard pattern that allows custom circuitry to be prototyped on the board itself. -
Page 13: Chapter 2: Installing The Maya2000 Series Spectrometers
You must install the operating software application prior to connecting your Maya2000 Series Spectrometer to a computer. The Ocean Optics SpectraSuite spectrometer operating software installs the drivers required for the Maya2000 Series spectrometer installation. If you do not install the software first, the system will not properly recognize the Maya2000 Series. -
Page 14: Configuring The Maya2000 Series Spectrometers
Connect Spectroscopic Accessories To find operating instructions for Maya2000 Series-compatible products (such as light sources, sampling chambers, and probes), consult the Software and Technical Resources CD or the Ocean Optics website at http://www.oceanoptics.com/technical/operatinginstructions.asp 020-00000-000-02-201207... -
Page 15: Chapter 3: Troubleshooting
Computer Prior to Software Installation Windows Operating Systems If you connected your Ocean Optics Maya2000 Series device to the computer prior to installing your SpectraSuite spectrometer operating software application on a Windows platform, you may encounter installation issues that you must correct before your Ocean Optics device will operate properly. -
Page 16: Remove Improperly Installed Files
The system is now able to locate and install the correct drivers for the USB device. Mac Operating Systems Since there are no device files for the Maya2000 Series Spectrometer in a Mac operating system, you should not encounter any problems if you installed the spectrometer before the SpectraSuite software. -
Page 17: Linux Operating Systems
3: Troubleshooting Linux Operating Systems For Linux operating systems, all you need to do is install the SpectraSuite software, then unplug and replug in the spectrometer. Technically, the driver files for Linux simply give nonprivileged users permission to use newly connected hardware. There isn’t any long-term harm to plugging in the device before installing the software. - Page 18 3: Troubleshooting 020-00000-000-02-201207...
-
Page 19: Appendix A: Calibrating The Wavelength Of The Maya2000 Series Spectrometers
This appendix describes how to calibrate the wavelength of your spectrometer. Though each spectrometer is calibrated before it leaves Ocean Optics, the wavelength for all spectrometers will drift slightly as a function of time and environmental conditions. Ocean Optics recommends periodically recalibrating the Maya2000 Series. -
Page 20: Calibrating The Spectrometer
A light source capable of producing spectral lines Note Ocean Optics’ HG-1 Mercury-Argon lamp is ideal for recalibration. If you do not have an HG-1, you need a light source that produces several (at least 4-6) spectral lines in the wavelength region of your spectrometer. - Page 21 A: Calibrating the Wavelength of the Maya2000 Series Independent Values Computed Dependent from the Regression Variable Variables Output Predicted True Wavelength (nm) Pixel # Pixel # Pixel # Difference Wavelength 253.56 0.09 253.65 30625 5359375 87616 25934336 296.72 0.01 296.73 302.15...
-
Page 22: Saving The New Calibration Coefficients: Usb Mode
► Procedure To save wavelength calibration coefficients using the USB mode, perform the following steps: 1. Ensure that the Maya2000 Series is connected to the PC and that you have closed all other applications. 2. Point your browser to http://www.oceanoptics.com/technical/softwaredownloads.asp scroll down to Microcode. - Page 23 A: Calibrating the Wavelength of the Maya2000 Series 020-00000-000-02-201207...
-
Page 24: Appendix B: Specifications
This appendix contains information on spectrometer operation, specifications, and system compatibility. It also includes accessory connector pinout diagrams and pin-specific information. How the Maya2000 Series Works The optical bench has no moving parts that can wear or break; all the components are fixed in place at the time of manufacture. -
Page 25: Maya2000 Series Components Table
B: Specifications Maya2000 Series Components Table Ocean Optics permanently secures all components in the Maya2000 Series Spectrometers at the time of manufacture. Only Ocean Optics technicians can replace interchangeable components, where noted. Item Name Description Secures the input fiber to the spectrometer. Light from the input fiber enters the Connector optical bench through this connector. -
Page 26: Maya2000 Series Spectrometers Specifications
B: Specifications Maya2000 Series Spectrometers Specifications The following sections provide specification information for the CCD detector in the Maya2000 Series spectrometers, as well as for each model Maya2000 Series Spectrometer itself. CCD Detector Specifications Specification Maya2000 Maya2000 Pro Maya200Pro VIS-NIR... -
Page 27: Maya2000 Series Spectrometer Specifications
B: Specifications Quantum Efficiency of S9840 Detector Quantum Efficiency of S10420 and S11510 Detectors Maya2000 Series Spectrometer Specifications Specification Maya2000 Maya2000 Pro Maya2000Pro VIS-NIR Dimensions (LxWxH) 148.6 mm (5.85 in.) x 109.3 mm (4.30 in.) x 50.4 mm (1.98 in.) Weight 0.96 kg (2.12 lbs.) -
Page 28: System Compatibility
You can use the Maya2000 Series’ USB connectivity with any computer that meets the requirements for the spectrometer operating software being used (Windows 98/Me/2000/XP, Mac OS X and Linux). See About SpectraSuite Software. 30-Pin Accessory Connector Pinout The Maya2000 Series features a 30-pin Accessory Connector, located on the side of the unit as shown: 020-00000-000-02-201207... -
Page 29: 30-Pin Accessory Connector Pinout Diagram
B: Specifications Location of Maya2000 Series 30-Pin Accessory Connector 30-Pin Accessory Connector Pinout Diagram When facing the 30-pin Accessory Connector on the front of the vertical wall of the Maya2000 Series Spectrometer, pin numbering is as follows: Port 30-Pin Accessory Connector Pinout Diagram 30-Pin Accessory Connector –... - Page 30 General purpose software-programmable, digital input/output GPIO (3) Input/Output (channel number) Input power pin for Maya2000 Series – When operating via or 5V Input or Output USB, this pin can power other peripherals – Ensure that peripherals comply with USB specifications (no TEC power)
-
Page 31: 30-Pin J2 Accessory Connector - Part Numbers
Input/Output (channel number) 30-Pin J2 Accessory Connector - Part Numbers The part numbers for the 30-pin accessory connector on the Maya2000 Series Spectrometer are as follows: • The connector is Pak50™ model from 3M Corp. Headed Connector – Part Number P50–030P1–RR1–TG. - Page 32 B: Specifications 020-00000-000-02-201207...
-
Page 33: Index
Index 30-pin accessory connector EEPROM, 3 diagram, 23 part numbers, 25 pin definitions, 23 filter, 19 focusing mirror, 19 accessories, 5, 8 Accessories, 4 accessory connector grating, 19 pinout, 22 Adobe Acrobat Reader, 5 Installation, 7 installed filter, 19 breakout box, 6 Interface, 4 Calibrating, iii, 13 memory chip, 3... - Page 34 Index troubleshooting Sampling Linux systems, 11 Accessories, 4 Mac systems, 10 System, 4 Troubleshooting, 9 service, iv setup, 7 shipment components, 5 slit, 19 SMA Connector, 19 upgrades, iv software USB-CBL-1, 4 SpectraSuite, 3 Software and Resources Library CD, 5 specifications, 18 detector, 20 spectrometer, 21...
