USB2000
Fiber Optic Spectrometer
Installation and Operation Manual
Document Number 170-00000-000-02-1005
Offices:
Ocean Optics, Inc.
830 Douglas Ave., Dunedin, FL., USA 34698
Phone
727.733.2447
Fax
727.733.3962
8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST
Ocean Optics B.V. (Europe)
Geograaf 24, 6921 EW DUIVEN, The Netherlands
Phone
31-(0)26-3190500
F ax
31-(0)26-3190505
E-mail:
Info@OceanOptics.com
Info@OceanOpticsBV.com
Orders@OceanOptics.com
TechSupport@OceanOptics.com (Technical support)
(General sales inquiries)
(European sales inquiries)
(Questions about orders)
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Ocean Optics USB2000
Summary of Contents for Ocean Optics USB2000
- Page 1 Ocean Optics, Inc. 830 Douglas Ave., Dunedin, FL., USA 34698 Phone 727.733.2447 727.733.3962 8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST Ocean Optics B.V. (Europe) Geograaf 24, 6921 EW DUIVEN, The Netherlands Phone 31-(0)26-3190500 F ax 31-(0)26-3190505 E-mail: Info@OceanOptics.com...
- Page 3 This manual is sold as part of an order and subject to the condition that it shall not, by way of trade or otherwise, be lent, re-sold, hired out or otherwise circulated without the prior consent of Ocean Optics, Inc. in any form of binding or cover other than that in which it is published.
-
Page 4: Table Of Contents
Configuring the USB2000 in OOIBase32 ..............................11 Connect Spectroscopic Accessories ................................13 External Triggering Options ..........................13 Troubleshooting ..........................14 USB2000 Connected to PC Prior to OOIBase32 Installation ................14 Remove the Unknown Device from Windows Device Manager ........................14 Windows 98:........................................15 Windows 2000/XP: ......................................16 Troubleshooting the Serial Port Configuration..................... - Page 5 Reflection Experiments............................24 Relative Irradiance Experiments.......................... 26 Time Acquisition Experiments ..........................28 Appendix A: Calibrating the Wavelength of the USB2000 ............31 About Wavelength Calibration ..........................31 Calibrating the Spectrometer ..........................31 Preparing for Calibration .....................................31 Calibrating the Wavelength of the Spectrometer............................32 Saving the New Calibration Coefficients: USB Mode..........................34...
-
Page 6: Usb2000 Introduction
The USB2000 Spectrometer connects to a notebook or desktop PC via USB port or serial port. When connected to the USB port of a PC, the USB2000 draws power from the host PC, eliminating the need for an external power supply. -
Page 7: About Ooibase32
Modular Sampling Accessories Ocean Optics offers a complete line of spectroscopic accessories for use with the USB2000. Most of our spectroscopic accessories have SMA connectors for application flexibility. Accordingly, changing the sampling system components is as easy as unscrewing a connector and replacing an accessory. -
Page 8: Interface Options
Interface Options The USB2000 has both USB and serial port connectors, enabling you to connect the spectrometer to a desktop or notebook PC via a USB port or to a desktop, notebook, or to a palm-sized PC via a serial port. -
Page 9: Software And Technical Resources Cd
Ocean Optics software, spectrometers, and spectroscopic accessories. You need Adobe Acrobat Reader version 6.0 or higher to view these files. Ocean Optics includes Adobe Acrobat Reader on the Software and Technical Resources CD. -
Page 10: Usb2000 Specifications
You can customize the items marked with an asterisk (*) when ordering the USB2000. Note: The optical bench has no moving parts that can wear or break. Ocean Optics secures all components in place permanently at the time of manufacture. -
Page 11: Usb2000 Component Table
USB2000 Specifications USB2000 Component Table Ocean Optics permanently secures all components in the USB2000 at the time of manufacture. Only Ocean Optics Technicians can replace interchangeable components, where noted. Item Name Description The SMA Connector secures the input fiber to the spectrometer. Light from the SMA Connector input fiber enters the optical bench through this connector. -
Page 12: Usb2000 Specifications
USB2000 Specifications USB2000 Specifications The following sections provide specification information for the CCD Detector in the USB2000, as well as the USB2000 Spectrometer itself. CCD Detector Specifications Detector: Sony ILX511 linear silicon CCD array Number of elements: 2048 pixels Pixel size: 14 µm x 200 µm... -
Page 13: System Compatibility
Any 32-bit version of Windows (when connecting the USB2000 to a PC via serial port) Compatibility for Palm-sized PCs In order to use the USB2000 with your palm-sized PC, the computer must meet the following requirements: • Palm-sized PC running Windows CE 2.11 or higher •... -
Page 14: 10-Pin Accessory Connector Pinout Diagram
When facing the 10-pin Accessory Connector on the USB2000, pin numbering is as follows: Figure 2-3: 10-Pin Accessory Connector Pinout Diagram 10-Pin Accessory Connector – Pin Definitions The following table contains information regarding the function of each pin in the USB2000’s 10-pin accessory connector: Pin #... -
Page 15: Installing The Usb2000
PC. The OOIBase32 software installation installs the drivers required for USB2000 installation. If you do not install OOIBase32 first, the system will not properly recognize the USB2000. If you have already connected the USB2000 to the PC prior to installing OOIBase32, consult Chapter 4: Troubleshooting for information on correcting a corrupt USB2000 installation. -
Page 16: Configuring The Usb2000 In Ooibase32
Default Spectrometer Configuration File The Default Spectrometer Configuration File screen prompts you to select a spectrometer configuration (.SPEC) file for use with the USB2000. The unique serial number of the USB2000 precedes the file extension (for example, USB2J0162.SPEC). Navigate to the OOIBase32 installation directory and select the spectrometer configuration file. - Page 17 Configure Hardware under the USB Serial Number drop-down screen. menu. 3. Select the COM port that the USB2000 is Note: The system pre-fills this drop-down connected to in the Serial Port drop-down menu with the serial numbers of all menu.
-
Page 18: Connect Spectroscopic Accessories
PC’s USB port, OOIBase32 pre-fills the coefficients for the USB2000 from information on a memory chip in the spectrometer. Otherwise, you must manually type the coefficients as they are printed on the Wavelength Calibration Data Sheet that accompanied your spectrometer. -
Page 19: Troubleshooting
USB2000 Connected to PC Prior to OOIBase32 Installation If you connect your Ocean Optics USB or PCI device to the computer prior to installing your Ocean Optics software application, you may encounter installation issues that you must correct before your Ocean Optics device will operate properly. -
Page 20: Windows 98
4. Navigate to the Windows | System32 | Drivers directory. 5. Delete the EZUSB.SYS file. 6. Reinstall your Ocean Optics application and reboot the system when prompted. 7. Plug in the USB device. The system will now be able to locate and install the correct drivers for the USB device. -
Page 21: Windows 2000/Xp
4. Navigate to the Windows | System32 | Drivers directory. 5. Delete the EZUSB.SYS file. 6. Reinstall your Ocean Optics application and reboot the system when prompted. 7. Plug in the USB device. The system will now be able to locate and install the correct drivers for the USB device. -
Page 22: Troubleshooting The Serial Port Configuration
USB2000’s COM port. 4. Verify that the COM port to which the USB2000 is interfaced is active. If the ports on the PC are not labeled and you do not know the COM port number, use trial-and-error to find the correct COM port. -
Page 23: Sample Experiments
Preparing for Experiments Follow the steps below to configure the USB2000 and OOIBase32 for experiments: 1. Double-check that you have correctly installed the USB2000, installed OOIBase32, and configured the light source and other sampling optics. 2. Open the OOIBase32 application, select Spectrometer | Configure from the menu bar, and double- check that A/D Interface settings are correct. - Page 24 If the signal you collect has too little light, you can increase the light level on scale in scope mode by: • Increasing the integration time • Using a larger diameter fiber • Removing any optical filters USB2000 Operating Instructions...
-
Page 25: Absorbance Experiments
Scope Mode from the menu bar. 2. Ensure that the entire signal is on scale. The intensity of the reference signal should peak at about 3500 counts. If necessary, adjust the integration time until the intensity is approximately 3500 counts. (Continued) USB2000 Operating Instructions... - Page 26 To permanently save the spectrum to disk, click the Save icon on the toolbar or select File | Save | Processed from the menu bar. Note: If you change any sampling variable (integration time, averaging, smoothing, angle, temperature, fiber size, etc.), you must store a new dark and reference spectrum. USB2000 Operating Instructions...
-
Page 27: Transmission Experiments
Spectrum | Scope Mode from the menu bar. 2. Ensure that the entire signal is on scale. The intensity of the reference signal should peak at about 3500 counts. If necessary, adjust the integration time until the intensity is approximately 3500 counts. (Continued) USB2000 Operating Instructions... - Page 28 To save the spectrum to disk, click the Save icon on the toolbar or select File | Save | Processed from the menu bar. Note: If you change any sampling variable (integration time, averaging, smoothing, angle, temperature, fiber size, etc.), you must store a new dark and reference spectrum. USB2000 Operating Instructions...
-
Page 29: Reflection Experiments
(top center), which is connected to the PC (far left). Common reflection applications include measuring the properties of mirrors and coatings. Other applications include measuring the visual properties of the color in paints, plastics, and food products. USB2000 Operating Instructions... - Page 30 To save the spectrum to disk, click the Save icon on the toolbar or select File | Save | Processed from the menu bar. Note: If you change any sampling variable (integration time, averaging, smoothing, angle, temperature, fiber size, etc.), you must store a new dark and reference spectrum. USB2000 Operating Instructions...
-
Page 31: Relative Irradiance Experiments
Common applications include characterizing the light output of LEDs, incandescent lamps, and other radiant energy sources such as sunlight. Relative irradiance measurements also include fluorescence measurements, which measure the energy given off by materials that have been excited by light at shorter wavelengths. USB2000 Operating Instructions... - Page 32 7. Click the Save icon on the toolbar or select File | Save | Processed from the menu bar to save the spectrum to disk. Note: If you change any sampling variable (integration time, averaging, smoothing, angle, temperature, fiber size, etc.), you must store a new dark and reference spectrum. USB2000 Operating Instructions...
-
Page 33: Time Acquisition Experiments
Steps 1-3 for Channel B. To configure a time acquisition process for the third, fourth, fifth, and sixth single wavelengths, select the Channel C, Channel D, Channel E, and Channel F pages, respectively, and set the necessary parameters. (Continued) USB2000 Operating Instructions... - Page 34 5. Name the Stream Filename for the time acquisition process. Clicking on the ellipsis to the right of this box opens a file save dialog box, allowing you to navigate to a designated folder. (Continued) USB2000 Operating Instructions...
- Page 35 Seconds, or Milliseconds to the right of the duration entry. Click the OK button to close the Time Acquisition Configuration dialog box. Then, enable Continue Until Manually Stopped, which instructs OOIBase32 to store data until you manually stop the acquisition process (optional). USB2000 Operating Instructions...
-
Page 36: Appendix A: Calibrating The Wavelength Of The Usb2000
This Appendix describes how to calibrate the wavelength of your spectrometer. Though each spectrometer is calibrated before it leaves Ocean Optics, the wavelength for all spectrometers will drift slightly as a function of time and environmental conditions. Ocean Optics recommends periodically recalibrating the USB2000. -
Page 37: Calibrating The Wavelength Of The Spectrometer
579.07 1122 1258884 1412467848 579.01 0.06 696.54 1491 2223081 3314613771 696.70 -0.15 706.72 1523 2319529 3532642667 706.62 0.10 727.29 1590 2528100 4019679000 727.24 0.06 738.40 1627 2647129 4306878883 738.53 -0.13 751.47 1669 2785561 4649101309 751.27 0.19 (Continued) USB2000 Operating Instructions... - Page 38 7. Record the Intercept, as well as the First, Second, and Third Coefficients. Additionally, look at the value for R squared. It should be very close to 1. If not, you have most likely assigned one of your wavelengths incorrectly. Keep these values at hand. USB2000 Operating Instructions...
-
Page 39: Saving The New Calibration Coefficients: Usb Mode
USB2000. You can overwrite old calibration coefficients on the EEPROM if you are using the USB2000 via the USB port. If you are using the USB2000 via the serial port, consult the Saving the New Calibration Coefficients: Serial Mode section later in this Appendix. -
Page 40: Saving The New Calibration Coefficients: Serial Mode
Appendix A Saving the New Calibration Coefficients: Serial Mode If you are connecting the USB2000 Spectrometer to the serial port of the PC, you need to save the new wavelength calibration coefficients to the .SPEC file that OOIBase32 accesses when opened. -
Page 41: Appendix B: Usb2000-Flg Spectrometer
On the USB2000-FLG, Ocean Optics has altered the functionality of the External Hardware Trigger function and reprogrammed the Single Strobe signal function. These alterations of the USB2000 enable you to operate in the Variable Delay Mode without the presence of an external trigger signal. The USB2000-FLG will simulate the signal to trigger the appropriate circuitry in the spectrometer. - Page 42 The strobe signal is a rising edge trigger signal that is TTL High for the entire delay period. See Figure B-2 for a timing diagram. The USB2000-FLG is now configured for operation in Variable Delay Mode. Figure B-1: The Acquisition Parameters Toolbar.
-
Page 43: Index
USB-CBL-1, 3 Installed Filter, 6 Variable Delay Mode, 36 Installing, 10 Wavelength Calibration, 31 L2 Detector Collection Lens, 6 Wavelength Calibration Data File, 3 Lens, 6 Wavelength Calibration Data Sheet, 3 Weight, 7 memory chip, 1 Mirror, 6 USB2000 Operating Instructions...
