Airthereal Day Dawning ADH80 - HEPA Air Purifier Manual

COMPONENTS

INSTALLATION

1. Rotate the bottom cover counterclockwise and remove the filter (which is sealed in plastic).

2. Remove the plastic seal from the filter (Note: the plastic seal must be removed, otherwise the machine will not work properly).

3. Place the filter back into the unit. Make sure the tag of the filter is facing outward. Close the bottom cover by rotating it clockwise.

4. Place the air purifier in a proper position at least 15 inches away from TVs, radios, and other electronic products. Electromagnetic interference from certain electronics may cause the product to malfunction. Only use the unit on firm and flat surfaces. Flimsy or slanted surfaces may result in abnormal noise and vibrations.


OPERATION

Follow these instructions to reduce the risk of serious injury or death and to reduce risk of damaging the unit.

1. This product comes with a regular adapter and a car adapter, making it suitable for indoor and car use.
2. Plug the adapter into a 120V power supply or the car cigarette lighter port. When plugged into a proper power source, the adapter power indicator will light up red.
3. Turn on the air purifier - the air purifier power indicator will light up red.

Touch-control panel Introduction

Power Button
Power on/off.
Press the button to switch on/off the air purifier. Once it beeps, the machine will start running on auto mode. Meanwhile, the power button light will turn from red to white. The unit detects air quality and will automatically change fan speeds in accordance with the surrounding environment after 10seconds.

Air quality indicator:
The table below shows air quality indicator colors and their corresponding air quality status and fan speed.

Fan Speed

Press the button to switch the fan speed from low to high (low, medium, and high) corresponding with the values 1, 2, and 3 on the panel.

Timer

When the power is turned on, pressing the timer button will cycle through 2hrs → 4hrs → 8hrs → Off → 2hrs etc. A green indicator light will appear next to the selected option. After 2 seconds, the unit will begin timing.

• If the timer reaches 0, and the unit is turned on, the unit will automatically turn off.
• If the timer reaches 0, and the unit is turned off, the unit will automatically turn on.

Sleep Mode
When the sleep mode is pressed, the LED nightlight and air quality indicators will be turned off. The air purifier will only work at the lowest fan speed. Pressing the button a second time will turn off sleep mode.

LED
Press this button to turn on/off the LED nightlight. Each press will cycle through Light Blue Light → White Light → Off → Blue light etc.

Child Lock Function:
Press the sleep and fan button simultaneously for 5 seconds to lock all buttons. Repeat the process to unlock all buttons.

MAINTENANCE

Know the 7-in-1 HEPA Filter

• It is recommended to replace the air filter every 6–8 months for optimal use, depending on the status of the filter.
• The following symptoms indicate that it's time to replace the air filter:
  • Increased noise
  • Decreased airflow
  • Clogged filters
  • Odors emitting from the filter
• when the replacement icon lights up, it is a reminder to check and change the air filter.
• Purchase a new Airthereal Replacement Filter.

www.airthereal.com
Search on Amazon: ADH80 HEPA filter
Only Airthereal Day Dawning ADH80 filters are compatible with this unit.

Replace the Air Filter

• Power off and unplug before operating.
• Follow INSTRUCTIONS to remove and replace the filter.
• Press and hold the button for 5 seconds to reset the replacement reminder.

Cleaning
Unplug the power cord before cleaning.

• The unit's exterior should be cleaned with a soft cloth moistened with mild soap. Thoroughly remove soap film with dry cloth.
• Open the bottom cover and clean the unit's interior and air outlet with a vacuum cleaner.
• For better maintenance, clean the air intake and air quality sensor hole every 2 months.

TROUBLESHOOTING

SPECIFICATIONS

SAFETY INSTRUCTIONS

Please read and comply with all of the instructions and warnings in the manual before using.

General Safety
Only use this air purifier as described in this manual.

• Ensure the DC adapter plug fits properly into an AC power outlet.
• When not being used, turn the air purifier off and disconnect it from its power source.
• DO NOT operate the unit if its cord or plug is damaged. Doing so may result in damage to the unit or personal injury. Any damages must be replaced by the manufacturer or a qualified technician.
• Only use the Airthereal original adapter for this unit.
• Thoroughly dry your hands before operation.
• DO NOT immerse the air purifier in water or liquids. It may result in damage to the appliance, electric shock, or fire.
• DO NOT use the air purifier outdoors.
• DO NOT use the air purifier in an enclosed space where flammable, combustible, or explosive gases are present.
• DO NOT use in areas where toxic vapors, flammable dust, or oxygen tanks are present.
• DO NOT insert fingers or objects into the air outlet.
• Child supervision is required while the air purifier is on. Do not allow children to play with the air purifier.

Use & Care

• Always place the air purifier on a flat, level surface while operation.
• Always leave 15 inches (38 cm) of clearance space around all sides of the air purifier.
• DO NOT place anything on the top of the air purifier.
• Keep the air purifier away from bug sprays, oil residues, burning incense, or chemical fumes.
• Always unplug the appliance from the power supply before servicing.
• DO NOT attempt to repair the air purifier without professional guidance. Contact Customer Support immediately if the air purifier fails to work.
• Only use Airthereal Day Dawning ADH80 filters for this unit.
• If you experience any problems while operating the air purifier, refer to the Troubleshooting section in the manual. If the problem is NOT solved, contact Customer Support.
• If the unit is damaged or NOT functioning properly, contact Customer Support.
